CKW-55 CHECKWEIGHER EN-11
3.3.1 Menu Structure
CALIBRATION (Sec. 4.1)
Span Perform
Linearity Perform
Calibration Test Perform
Geo Factor: 0…16...19…31
End
SETUP (Sec. 3.6.1)
Reset: No, Yes
Legal-For-Trade: Off, On
Calibration Unit: kg, lb
FS Capacity: Numeric Entry
Graduation: Numeric Entry
Zero Range: 2%,18%, 100%
Retain Zero Data: Off, On
Auto-Tare: Off, On, On Acc
Beep Volume: Off, Lo, Hi
Key Beep: Off, On
End
READOUT (Sec. 3.6.2)
Reset: No, Yes
Unit: kg, lb, g, oz, lb:oz, %
Stable Range: .5d, 1d, 2d, 5d
Averaging Level: Lo, Med, Hi
Auto-0 Tracking: Off, .5d, 1d, 3d
LED Brightness:
Off, Lo, Med, Hi
Bar Brightness: Off, Lo, Med, Hi
Power Saver: Sleep, Auto-off
End
COM (Sec. 3.6.5)
Reset: No, Yes
Baud Rate: 300, 600, 1200, 2400,
4800, 9600,19200
Parity: None, Even, Odd
Data Length: 7, 8
Stop Bit:
1, 2 22 22
Handshake: None, XON/XOFF
Type:
RS232, RS485
Alt Command: Print, Tare, Zero
End
PRINT (Sec. 3.6.4)
Reset: No, Yes
Stable Only: Off, On
Auto Print Mode: Off, Stable, Interval,
Continuous, On Accept
Print Content: Display, Numeric,
Header, Setpoint,
Gross, Net, Tare,
Status, GMP,
Accumulation
Layout: Format, Feed
List: Menu, Library
End
MODE (Sec. 3.6.3)
Reset: No, Yes
Checkweigh: Off, On
Library: Off, On
Set Point Input: Range, Variance, %
Beeper Signal: Off, Accept, Under,
Over, Under-Over
Display Signal: Off, Accept, Under,
Over, Under-Over
Graph Increment: Scaled, Auto, User
Graph Display:
Segment, Bar, Block
End
I/O (Sec. 3.6.6)
Reset: No, Yes
External Input: Off, Tare, Zero, Print,
Units, GNT, Accumula-
tion, Start-Stop,Tare-
Start-Stop
Input Beep: Off, On
Relay Output: Type, Sequence, Contact,
Stable
End
GMP (Sec. 3.6.7)
Reset: No, Yes
User ID: Enter 6 characters
Project ID: Enter 6 characters
Scale ID: Enter 6 characters
Date: Format, Set
Time: Format, Set
End
LOCK (Sec. 3.6.8)
Menu: Reset, Cal, Setup, Read,
Mode, Print, Com, I/O,
GMP Data
Key Function: Reset, Num, Clr, Target,
Lib, Lib Save, Next, Zero,
Print, Units, GNT, Tare,
Menu
End
NOTES: 1. Bolded items indicate factory default settings.
2. The unit selected for “Calibration Unit” will become the default “On” unit in the event that all other units are set to “Off”.
3. When the Legal for Trade setting is changed to “On”, the following items are affected:
i. Span and Linearity calibration are unavailable, Geo factor is viewable but not alterable, Cal Test will operate.
ii. Underlined menu items become forced as default.
4. Some menu items may only become available when certain optional accessories are installed.
5. Using the Reset function in the “SETUP” menu will not change the values entered for FS Capacity or Graduation.
