** The optical flow alarm is only equipped with pre-amplifier K-FA-H, the electronic controller must be ordered separately.
Technical Data
FM-2K FM-200K-H FM-200K-H/FA
Part-No. 09F2105 09F2505 09F2555**
Heated / needle valve in the inlet no yes
Optical flow control, mono-stable** no fix between 20-50 % of scale
Standard measuring range, at 1,2 bar, 20 °C 25-250 l/hr air
Measuring ranges available Scale: 1,6-16; 6-60; 10-100; 25-250; 50-500; 80-800 l/hr air, 1,2 bar, 20 °C
Operating pressure / operating temperature max. 2 bar g/ max. +180°C
Ambient temperature -40 to +180 °C -25 to +60 °C -25 to +50 °C
Storage temperature -40 to +80 °C -25 to +80 °C
Gas connections 1/4" NPT i Tube fittings Swagelok ø6 mm, optional ø1/4"
Temperature controller Capillary thermostat, integrated in electrical connection box with high
temperature limiter and low temperature alarm contact
Operating temperature adjustable from 0 to 180 °C, set in factory at 180 °C
Low temperature alarm contact change over contact, voltage free; contact rating 250V, 3A~, 0,25A=,
alarm point ∆T 30 °C
Power supply 230V 50Hz, 220VA optional 115V 60Hz (a)
Electrical connections Terminals 4 mm 2 , 2x Cable glands PG13
Protection / Electrical standard IP 54 EN60529 / EN 61010, EN60519-1
Dimensions 50 x 290 x 50 mm(w x h x d) 250 x 500 x 140 mm(w x h x d)
Weight 0,8 kg 8 kg 8,5 kg
Stagnant space / Mounting approx. 6 cm 3 / wall mounting
Material of sample contacting parts glass, stainless steel 316Ti, PTFE
