M&C TechGroup Germany GmbH • Rehhecke 79 • 40885 Ratingen • Germany

[email protected] • www.mc-techgroup.com • Fon +49 2102 935-0 • Fax +49 2102 935-111

13.4

Technical specifications and illustrations are without

obligation, subject to modifications. 05.97/11.12

GasflowdiagramPMA30

1

2

3

FLA

4

1. External fine filter

2. Flowmeter with needle valve

3. Oxygen measuring cell PMA

4. Flow alarm sensor

Dimensions

Dimensions in mm

Front view

Side view

3HE (129)

2

28

28TE (142)

32

230

80

30

25

100

Heater

Status

20

5

15

10

VOL.% O

2

2

O -Analyser

PMA30

60

40

20

0

0

Span

1

3

100

Ext.

10

30

Zero
