11.7
Technical specifications and illustrations are without
obligation, subject to modifications. 02.96/12.06
Flexible tubes Typ SL1-... Typ SL2-...
Material
Trade mark PTFE Polytetrafluorethylene
Teflon
®
FPM Fluorcarbon-Rubber
VITON
®
Part-No. 01U0010 02B1000 02B2000 02B2500 02B3000 90A0055 01T1000 01T1005
Flexible tube types SL1-
0,7/2 SL1-
4/6 SL1-
6/8 SL1-
8/10 SL1-
10/12 SL2-
2/4 SL2-
4/6 SL2-
6/8
Hose / Tube ø i x o (mm) 0,7 x 2,0 4 x 6 6 x 8 8 x 10 10 x 12 2 x 4 4 x 6 6 x 8
Tolerance ø / wall thickness DIN 7715-2 DIN 7715-2
Operating temperature, max. -190°C to +200°C -20°C to +180°C
Operating pressure, max.
at 20 °C (bar abs.) 0 - 11 0 - 11 0 - 9 0 - 7 0,5 - 5 0,1 - 7 0,3 - 5 0,4 - 4
Weight (g/m) 9 34 47 60 75 18 29 40
Length of the tube coil (m) 1 / 2 / 50 50 / 100 50 / 100 50 / 100 50 2 / 40 40 40
Smallest bending radius (mm) 10 40 70 100 150 30 40 70
Analysis quality, natural pure yes yes
Non adhesive surface yes no
UV-resistant yes yes
Colour white black
Technical Data
Flexible tubes Typ SL3-... Typ SL4-... Typ SL5-...
Material, Trade Mark NOVOPREN ® PVC Polyvinylchloride TYGON ®
Part-No. 01T2000 01T4000 01T4100 01T4200 01T4500
Flexible tube types SL3-
3,2/6,4 SL4-
4/6 SL4-
4/8 SL4-
6/8 SL5-
3,2/6,4
Hose / Tube ø i x o (mm) 3,2/6,4 4 x 6 4 x 8 6 x 8 1/8" x 1/4"
Tolerance ø / wall thickness DIN 7715-2 DIN 7715-2 DIN 7715-2
Operating temperature, max. -10°C to +100°C -10°C to +60°C -40°C to +70°C
Operating pressure, max.
at 20 °C (bar abs.)
0 - 11 0,4 - 7 0 - 11 0,5 - 5 0,2 - 9
Weight (g/m) 43 22 40 31 33
Length of the tube coil (m) 1 / 10 100 5 / 100 100 5 / 15
Smallest bending radius (mm) 40 40 70 70 40
Analysis quality, natural pure yes yes yes
Non adhesive surface no no no
UV-resistant yes yes yes
Colour green/gray transparent transparent
PVC-tubes are not applicable for continuous use with overpressure.
Flexible tubes Typ SL6-... Typ SL7-... Typ SL8-...
Material
Trade Mark PFA Perfluoralkoxy PA Polyamide
NYLON
® flexible
PE Polyäthylene
Part-No. 01T5000 01T6000 01T6100 01T6200 01T7000
Flexible tube types SL6-
4/6 SL7-
4/6 SL7-
6/8 SL7-
8/10 SL8-
4/6
Hose / Tube ø i x o (mm) 4 x 6 4 x 6 6 x 8 8 x 10 4 x 6
Tolerance ø / wall thickness DIN 7715-2 DIN 7715-2 DIN 7715-2
Operating temperature, max. -180°C bis +200°C -10°C to +70°C -20°C to +60°C
Operating pressure, max.
at 20 °C (bar abs.)
0 - 11 0 - 26 0 - 19 0 - 15 0 - 9
Weight (g/m) 34 17 23 30 15
Length of the tube coil (m) 25 50 50 50 50
Smallest bending radius (mm) 100 40 70 100 40
Analysis quality, natural pure yes yes yes
Non adhesive surface yes no no
UV-resistant yes yes no
Colour white milky milky
To cut the tube accurately, we recommend:
Hose cutter, Part-No.: 10T1000
Other materials, dimensions or coloured versions are available..
