6.1
Technical specifications and illustrations are without
obligation, subject to modifications. 10.96/06.06
Gas cooler serie EC ® ECP 1000 ECP 2000 ECP 3000
Part number with glass heat exchanger 01 K 1000 01 K 2100 01 K 3100
Part number with stainl. steel heat exchanger 01 K 2000 01 K 2200 01 K 3210
Part number with PVDF heat exchanger 01 K 3000 01 K 2300 01 K 3300
Number of heat exchanger 1 2 1
Gas flow rate per heat exchange max. 150 Nl/h** max. 350 Nl/h**
Ambient temperature +5 to +45 °C, +50 °C* +5 to +50 °C +5 to +50 °C
Storage temperature -20 to +60°C
Sample outlet dew point range of adjustment: +2 °C ..... +15 °C, factory setting: +5 °C
Dew point stability ± 0,1 °C at constant conditions
Sample inlet temperature max. 180 °C**
Sample inlet dew point max. 80 °C**
Total cooling power at +25 °C ambient 54 KJ/h 97,2 KJ/h 97,2 KJ/h
Power consumption 100 VA 110 VA 110 VA
Main connection 230 V ± 10%, 50Hz or 115 V ± 10%, 60Hz
Ready for working < 10 min.
Electrical connection Terminals 2,5 mm
2
, cable gland 2 x PG 11.
Status alarm: 2 changeover contacts Contact rating: 250V, 2A, 500VA, 50W, Alarm point: ∆ T ±3 °C zu T
soll
Case protection IP 22; EN 60529
Electrical standard EN 61010
Case colour RAL 9005
Method of mounting wallmounting
Dimension/Weight 5,5 kg 7 kg 7 kg
Heatƒexchanger
Material of heat exchanger
Duranglass ® PVDF stainless steel 316Ti
Admissible gas pressure 3 2) / 2 3) 3 / 2 3) 10 bar
Sample gas connection for tube ø6 mm, 8 o. 10 mm* G 1/4’’ i G 1/4’’ i, NPT*
Condensate connection for tube ø12 mm, 10 o. 8 mm* G 3/8’’ i G 3/8’’ i, NPT*
∆ P per heat exchanger at 1 mbar at 150 l/h 1 mbar at 150 l/h 5 mbar at 350 l/h
Stagnant space per heat exchanger 50 ml 50 ml 100 ml
Technical Data
* Option
** Maximum values in technical datas must be rated in consideration of total cooling capacity at 25 °C ambient temperature and an outlet dew point of 5 °C.
1) Others on request.
2) With GL-adapter.
3) Max. 2 bar abs. with peristatic pump SR25.1.
GL adapter and tube fittings for the connection of differerent tube diameters at the heat exchanger see chapter 11, data sheet 11.5 and 11.6.
