M&C TechGroup Germany GmbH • Rehhecke 79 • 40885 Ratingen • Germany

[email protected] • www.mc-techgroup.com • Fon +49 2102 935-0 • Fax +49 2102 935-111

6.3

Technical specifications and illustrations are without

obligation, subject to modifications. 10.99/06.06

*

Standard, other version on request.

**

Option

*** Maximum values in technical data’s must be rated in consideration of total cooling capacity at 25 °C ambient temperature and 5 °C outlet dew point.

2)

With GL-Connecting adapter.

3)

With SR25.2 max. 2 bar abs.

GL-adapter and tube fittings for the connection of different tube diameters at the heat exchanger see chapter 11, data sheet 11.5 and 11.6.

Technical Data

Order example:
1 cooler ECM-2 with 2 heat exchangers out of glass ECM-2G and 2 peristaltic pumps SR25.2, power 115V 60Hz:

Part. No. 1x 02K7510Xa; 2x 97K0100; 2x 01P9125

Gas cooler series EC

®

version ECM-1

version ECM-2

version ECM-EX2-1

version ECM-EX2-2

Part No. for basis cooler without heat exchanger

02K7500X* (a)**

02K7510X* (a)**

02K7600X* (a)**

02K7610X* (a)**

Number of heat exchanger possibility-

1

2

1

2

Ambient temperature

+10 up to +50 °C

Storage temperature

-20 to +60°C

Sample outlet dew point

range of adjustment: +2 °C ..... +7 °C, factory setting: +5 °C

Dew point stability

at constant conditions < ±0,1 °C

Sample inlet temperature***

max. 180 °C

Sample inlet dew point***

max. 80 °C

Total cooling capacity

144 KJ/h at +10 up +50 °C ambient

Ready for working

<15 min.

Main power connection / power consumption

230V AC* or 115V AC**(a) -15%/+10%, 50/60 Hz, max. 200VA
start up current: 230V 50Hz = 2,5A / 115V 60Hz = 4,5A

Electrical connection

terminals 2,5mm

2

, 2x PG11 cable gland (with FM-approval conduit-hub 1/2” NPT)

Status alarm-2 contacts, potential free

contact rating 250VAC, 2A, 500VA, 50W, alarm point <+2 °C and >+8 °C*

Case protection / Electrical standard

IP20 EN60529 / EN 61010

II 3 G EEx nAC [L] IIC T4 ATEX

Class I, Div.2, Group A, B, C, D, T4 (FM

approval for 115V execution only)

Method of mounting / Case colour

wall mounting / RAL 9003

Dimension / Weight

270x270x316 mm (w x h x d) / 12/13,5 kg Version 230V / 115V

Options for basis cooler

ECM-1.. and ECM-EX2-1..

ECM-2... and ECM-EX2-2

Heat exchanger type

ECM-1G

ECM-1PV

ECM-1SS

ECM-2G

ECM-2PV

ECM-2SS

Part No.

93K0140

93K0170

93K0160

97K0100

97K0110

97K0115

Material of heat exchanger

Duran glass

PVDF

st. steel 316Ti

Duran glass

PVDF

st. steel 316Ti

Max. gas flow rate per h.e.

250 Nl/hr***

250 Nl/hr***

250 Nl/hr***

150 Nl/hr***

150 Nl/hr***

150 Nl/hr***

Gas press. max. bar abs.

3)

2 / 3

2)

3

10*

2 / 3

2)

3

10*

Sample gas connection

GL18 for
ø 6 mm
o.d. tube*

G1/4’’i

G1/4’’i* or
1/4’’NPT**

GL18 for
ø 6 mm
o.d. tube*

Tube ø 6 mm*

Tube ø 6 mm

Condensate connection

GL⁄25 for
ø 12mm tube*
ø 8mm
or ø 10mm**

G3/8’’i

G3/8’’i or
3/8 NPT**

GL25 for
ø 12 mm tube*
ø 8 mm
or ø 10 mm**

G3/8’’i

G3/8’’i or
3/8 NPT**

∆P at max. flow rate

1 mbar

1 mbar

1 mbar

1 mbar

1 mbar

1 mbar

Stagnant space approximately

100 ml

100 ml

100 ml

40 ml

25 ml

30 ml

Peristaltic pump SR25.2

1 pc. incorporated in the cooler, compl. installed, Part No.: 01P9125 cooler weight plus 0,6 kg per pump

Options
