TechnicalData
WARNING!IMPORTANT!
An external fine filter must always be used at the gas inlet of the analyser. Depending
on the composition of the sample gas, it may be necessary to use a sample conditio-
ning system.
VersionPMA50EEXthermostatedoxygenanalyserinexplosion-proofhousing
Part No. 05A1000 :
05A2500 :
05A2505 :
PMA 50 EEX, power supply 230V 40-60Hz, signal 0-1V and 0-20mA
PMA 50 EEX/P/PD-1-50, power 230V 40-60Hz, 0-1V / 0-20mA, pressure compensation 0,6 - 1,5 bar abs. with purging
the enclosure via two certified ventilate arrestors in the in- and outlet NPT1/4“i
PMA 50 EEX/P/PD, power 230V 40-60Hz, 0-1V / 0-20mA, pressure compensation 0,6 - 1,1 bar abs.
05A1000a / 05A2505a / 05A2505a = 115V 40-60Hz
(variations of +10% to -15% have no influence on the function of the analyser), 40-60Hz, 35,5VA, power supply via
EEx e connecting box, diameter of cable: 5mm - 9mm (PG13,5), 7mm - 12mm (PG16)
Measuring ranges selectable for 0-1, 0-3, 0-10, 0-30 and 0-100 vol.% O
2
linear and position EXTERNAL
External range indication externally: Potentialfree contact for all measuring ranges. Capacity 48V DC 200mA DC, Minimum contact rating
5V/1mA; internally : LED indication
Remote range control Measuring ranges selectable via external potential free contacts 30V DC 3mA DC
Combined analogue/digital indicator analogue meter with a scale of 0-30 and 0-100% for each selected range
digital meter 3
1 /
2
digit 9 mm high LCD-indicator for 0-100% O
2
reading, selectivity 0,1vol.% O
2
Output signals 0-10V DC, burden >100 KΩ for range 0-100 % isolated.
0/4-20mA burden 270 Ω for every measuring range, electrically isolated; output voltage max. 15V (ex works).
Switchable max. burden 800 Ω, output voltage max. 30V.
Output current limiting adjustable 20mA-22mA (20,5mA ex works)
Response time for 90% FSD < 5 seconds at 60 Nl/hr air
Accuracy after calibration deviation: analogue signal output = ± 1% of span at range 3 - 100% / digital indicator = ±0,1 vol.% O
2
= ± 2% of span at range 1%
Reproducibility deviation: analogue signal output = < 1% of span / digital indicator = ±0,1 vol.% O
2
Influence of ambient temperature no influence up to 50 °C
Influence of barometric pressure The oxygen reading varies in direct proportion to changes of the barometric pressure
# no influence from 0,5-1,5 bar abs. at PMA 50 EEX/P/PD-1-50 with process pressure compensation
Influence of sample gas flow Variation in gas flow between 0-60 Nl/hr air will cause a difference of < 0,2 vol.% O
2
Sample gas inlet pressure 0,01-0,1 bar g standard or # in case of purging up to 0,5 bar g
(PMA 50 EEX required admission pressure for competent flow rate, no pump inside)
Sample gas outlet pressure outlet of analyser must discharge freely into atmosphere
or 0,6-1,5 bar abs. at version # PMA 50 EEX/P/PD-1-50 with process pressure compensation
Flow rate of sample gas max. 60 Nl/hr (no flowmeter inside)
Temperature of sample gas -10 °C up to +50 °C dry gas
O
2
-transducer temperature fixed at +55 °C
Ambient-/ Storage temperature -10 °C up to +50 °C / -20 °C up to +60 °C, relative humidity 0-90% RH
Power supply internal power unit for 230V AC standard or 115V AC (a)* +/-10%, 40-60Hz, 35,5VA
Electrical connections terminals 2,5 mm
2
, 3x PG cable glands (mains supply, signals, range indication, remote ranging , status alarm)
Materials in contact with sample gas Platinum, Glass, Stainless Steel 316Ti, Epoxy resin, PTFE, PVDF
Sample gas connection
1 /
4
" NPTi
Flow alarm thermo-conductive flow sensor downstream mounted after measuring cell
Status alarm Change-over contact, switching capacity 250 V AC 2A AC, 48V DC 200mA DC minimum contact rating 50mW for
temperature <+45°C / >+60°C, defect light beam, measuring cell not coupled, flow alarm <10 / >70Nl/h, power
supply error control, mains voltage breakdown
Protection / classification
IP 54 EN 60529 / II2G EEX d e IIC T5 or II1/2G EEX d e [ia] IIC T5
Certificate No. KEMA 03 ATEX 2215X
Temperature cutoff at 72°C via thermal fuse, non-reversible
Housing / colour wall mounted explosion-proof housing / blue
Dimension / weight 475 (535) x 275 (355) x 200 mm / h x w x d / approx. 22 kg
Options Part-No. 05A9000: purging the enclosure via two certified ventilate arrestors, for pressures up to max. 1,5 bar abs.
and/or corrosive gases, connection
1 /
4
" NPTi, purge gas inlet pressure max. 100 mbar, flow rate 10-60 Nl/hr
Part-No. 05A9005: purging the enclosure via one certified ventilate arrestor, for pressure range > 1,1 bar - 1,5 bar abs.
and non-corrosive gases, connection
1 /
4
" NPTi
Part-No. 05A9015: Zero suppressing type SD-1/50 for PMA-50 pressurerange 0,5-1,5bar abs. Lowest range 97-100%
material: SS316, PVDF, Viton. mounted in the PMA-50Ex. Only in connection with PMA50EEx/P/PD-1/50.
Externally switchable via potential free contacts, 30V DC 3mA DC
Part-No. : Transmitter for measurements of gases from ex-zone 0
II 1/2 G Eex de [ia] IIC T5
Part-No. 90A0009: Measuring cell type PMC-1LB, solvent resistant.
Part-No. 90A0006: Measuring cell PMC-1G with glass solder. O-ring made of Chemraz
* Please specify with order.
