8
Gas sampling and conditioning technology 5-6.10-ME
8 TECHNICAL DATA
Flow alarm sensor Type FA-1, bi FA-2, bi FA-3, bi
Part-No. 02E1000 02E2000 02E3000
Meter tube 5-14 mm 13-27 mm 26-55 mm
Dimensions B x T x H in mm 35 x 23 x 15 63 x 40 x 22 103 x 75 x 25
Weight 50 g 100 g 200 g
Operating temperature -25°C to +70°C
Storage temperature -25°C to +70°C
Electrical connection 3 m connection cable standard; ø 4,5 mm, 4 cores (for each additional meter of sensor connection cable
= Part-No.: 02E9000, max. 10 meters) (>10 m = with pre-amplifier K-FA.. max. 200 meters)
Mounting With clamping screw
Function Bi-stable and mono-stable
Power supply voltage From electronic controller FA...
Protection type IP65 EN 60529
Material Aluminium anodised, epoxy, PVC cable, semi-conductors
Electronic Controller Type FA-1.1 FA-1.4 K-FA**
230V 50/60Hz
115V 50/60Hz
24V
DC
24V AC
02 E 7300*
02 E 7300*
02 E 7300 d
02 E 7300 b
02 E 7110
02 E 7110 a
02 E 7110 d
02 E 7110 d 02 E 4020
Mounting Wall mounting housing Rail mounting housing
EN 50022 Wall mounting housing
Sensor inlets 1 11
Function mono-stable / bi-
stable / KS 2 all, selectable via electrical assignment mono- or bi-stable
Power consumption 2 VA 1 VA 1 VA
Alarm Relay
(MC/NC/NO)
Contact rating max. 250V AC/DC
AC=500VA, DC=50W, 3A
250V AC / DC ,
AC=500VA, DC=45W, 2A
Pull-in/drop-off time lag
of alarm relay 2 sec.
Cable inlet 1x clamping range 3mm - 6,5mm
2x clamping range 5mm - 10mm 1x clamping range 3mm - 6,5mm
1x clamping range 5mm - 10mm
Electrical connection Terminals max. 2,5 mm 2
Adjustment of sensitivity for
sensor FA.. After removing the lid on the
potentiometer On the front side of the housing
on the potentiometer
Distance between sensor
and electronic FA-.. max. 10m >10m, max. 200m
Line break monitoring Yes
Protection type IP65 EN 60529 IP20 EN 60529 IP65 EN 60529
Housing material Polycarbonate Polyamide Polycarbonate
Ambient temperature -25°C to +60°C
Electrical standard EN61010
Dimensions W 80 x L 160 x H 55 mm W 22,8 x L 100 x D 111 mm W 80 x L 160 x H 55 mm
Weight 0,31 kg 0,18 kg 0,3 kg
* reversible mains voltage 230V 50Hz / 115V 60Hz, adjusted at works: 230V 50Hz.
**To be used in connection with electronic controller FA-1.1 or FA-1.4 for cable lengths of above 10m between forked light barrier and
electronic controller
Serie FA
®
Version FA-1.4
