background image

M&C TechGroup Germany GmbH • Rehhecke 79 • 40885 Ratingen • Germany

[email protected] • www.mc-techgroup.com • Fon +49 2102 935-0 • Fax +49 2102 935-111

2.9

* Standard, ** optional

Technical Data

Technical specifications and illustrations are without

obligation, subject to modifications. 10.04/11.12

Gas sample probe type

SP3000

Part No.

20S5500

Weather protection shield

yes

Filter housing material

Stainless steel 316 / 316Ti

Sealing materials

Graphite

Probe flange sealing material

Graphite

Pre-filter

optional, for a valid Ex-approval according to ATEX the probe SP3000 has to be operated with a pre-
filter from page 4

Sample pressure max.

0,5-6 bar abs.

Ambient temperature

-20 °C to +60 °C

Permissible process gas temperature

depending on the temperature class, however max. 200°C at the probe entry

Filter chamber volume

120 cm

3

Filter element, porosity

F-3SS150= stainless steel*, 3 micron S-2K150= ceramic**, 2 micron,

Sample gas outlet connection

1x 1/4“ NPTi for max. 8mm-tube connectors

Connection gas outlet at option RS

6 mm Swagelok connector

Mounting flange

DN65 PN6, FormB, SS316Ti* >DN or ANSI possible**

Weight

7 kg

Marking

II 1D/2GD -20°C ≤ Ta ≤ +60°C EXAM BVS 04 ATEX H 045X

Marking with option RS

II 1D/2GD -20°C ≤ Ta ≤ +60°C EXAM BVS 04 ATEX H 045X

Option back purge unit type RS

RS

Part No.

20S5560 (a)

Power supply

230V 50/60Hz 9W or 115V 50/60Hz 9W (a)

Electrical connection

cable 3x1mm

2

Marking

II 2GD EEx m II 135°C

Connection

G1/2” at the buffer vessel

Max. back purge pressure

6 bar abs.

Volume buffer vessel

2 liters

Ambient temperature

-20°C to 60°C

Option heating type HEX4

HEX4-135

HEX4-180

Part No.

20S5510

20S5520

Control

self-regulating

Power supply

115V - 230V 50/60Hz

Electrical connection

cable gland, terminal range 7 - 12mm, terminals max. 4mm

2

Marking

II 2G EEx em T4 /

II 2D IP66 135°C EXAM

BVS 04 ATEX E 253

II 2G EEx em T3 /

II 2D IP66 180°C EXAM

BVS 04 ATEX E 253

Power

400W

Case protection

IP66; EN60529

Max. temperature

120 °C

160 °C

Min. temperature

90 °C

120 °C

Ambient temperature

-20 °C to +60 °C

Low temperature alarm contact

<60°C, 1 contact MC-NO, 230V 1,5A AC, 0,5ADC

<100°C, 1 contact MC-NO, 230V 1,5A AC, 0,5ADC

Option 2-way-ball valve in the probe entrance

/VA

Part No.

20S9050

Operating temperature

-20°C up to +185°C

Option 2/3-way-ball valve in the probe entrance

/3VA

Part No.

20S9325

Backflush / Test gas connection

6mm tube

Operating temperature

-20°C up to +185°C

Option pneum. drive for ball valve /VA o. /3VA

MS1

Part No.

20S9055

Connection control air

G1/4” i

Pressure control air

5-10 bar

Temperature class

T4

Option second sample gas outlet

/2X

Part No.

20S9015

Connection

1/4” NPT i
