Issue 1.60.C Epsio Version 1.60 – User’s Manual
EVS Broadcast Equipment - July 2010
E
PSIO
M
AIN
M
ENU
ChromaK OSD
Graph <-- Calib Calib --> Detect
The Epsio main menu contains the following commands:
Command Description
Graph Allows the user to display or hide the Epsio animation that
has been created. The Graph command is active when you
enter the Epsio menu.
ChromaK Allows the user to enter the Chroma Key menu, in which you
can configure the chroma key definition.
Refer to the section 2.4.2 ‘Accessing the Chroma Key Menus’,
on page 29.
OSD Allows displaying or hiding the OSD information on the output
monitor. By default, the OSD information is displayed.
<-- Calib Allows moving to the previous calibration angle in the
Calibration tab of Epsio.
Calib--> Allows moving to the next calibration angle in the Calibration
tab of Epsio.
Detect Allows performing an automatic detection of the playfield
limits when one of the live tools is active. This option is only
available with the live tools.
S
ECONDARY
M
ENU
The secondary menu contains the various tools you can use in Epsio.
To access or leave the secondary menu, press the MENU key on the Remote
Panel.
Offside Arrow Circle Graphics
To activate a tool in the secondary menu, click the key corresponding to the
requested tool: Offside (A), Arrow (B), Circle (C), Graphics (D).
48
