General Parameters
The general parameters associated to the loaded target are displayed on the left.
These parameters are described in the table below.
Field/Button Description
Specifies the color of the selected component.
Click the color frame to open the color palette,
and select the requested color.
Slider that allows defining the transparency of
the Alpha layer of the selected component.
The Alpha field allows defining the
transparency for individual components,
whereas the black level of the chroma key
allows defining the general transparency for the
offside line animation.
Displays the result of the color selection (RGB)
for the loaded target.
Displays the result of the alpha channel
selection for the loaded target.
Drop-down field to select the font to be used
for the text to be displayed.
Specific Parameters
Other more specific parameters associated to the loaded target are displayed in a
table on the right:
To edit these parameters, double-click the parameter. This opens a dialog box
similar to the following one, and in which you can modify the parameter value:
