Epsio Version 1.60 – User’s Manual
EVS Broadcast Equipment – July 2010
Issue 1.60.C
F
IELDS AND
C
OMMANDS IN THE
CHROMA T
AB
The following table describes the field boxes and buttons on the tab:
User Interface
Element Description
Profiles area
EVS Profiles list Lists the chroma key profiles available in the Chroma Key
edit screen of the LSM Remote Panel:
• Clicking the profile will load a preview of the chroma key
on the preview area.
• Double-clicking the profile will load the chroma key
parameters in the CHROMA tab and the chroma key
definition for the current image of PGM1 if you are in the
Chroma Key edit screen on the LSM Remote Panel. This
image will show in the Epsio operating monitor.
Preview Shows a preview of the chroma key profile selected in the
list.
Snap Button used to snap the current image from PGM1 and
loads it onto the operating monitor.
Load Button used to load the profile selected in the Settings
area.
Save Button used to save the chroma key values defined for the
chroma key profile loaded into the CHROMA tab.
Settings area
Color space Shows the color range for the chroma key definition.
Also refer to the section ‘Chroma Key Parameters’, on
page 31.
Adjustment sliders Each slider allows modifying one of the chroma key
parameter of the loaded chroma key profile.
Also refer to the section ‘Chroma Key Parameters’, on
page 31.
Note
When you are refining the Chroma key in Epsio, you can toggle between
the chroma key and the image showing the final incrustation by right-
clicking the mouse.
35
