background image

Epsio Version 1.60 – User’s Manual

EVS Broadcast Equipment – July 2010

Issue 1.60.C

2.4.4 C

HROMA

K

EY

E

DIT

S

CREEN ON THE

R

EMOTE

P

ANEL

I

NTRODUCTION

You define and manage the chroma key definition from the Chroma Key edit
screen. When you are in this screen, the Edit mode is directly active.

Chroma key

Server

Edit Screen

F1: X

F5: X Transition

F2: Y

F6: Y Transition

F3: Width

F7: Black Level

F4: Height

F8: Toggle View

Auto

Save

Save As

Quit

Profile 1

Profile 2 Profile 3 Profile 4

In addition, the color space is also displayed at the top left of the operator’s PGM

monitor when you define the chroma key. It allows you to visualize the range of
colors taken into account in the chroma key definition.

For more information refer to the sections:

Section ‘Available Commands’ (page 33)

Section ‘Chroma Key Parameters’ (page 31)

Section ‘How to Configure a Chroma Key Based on an Automatic Chroma Key’

(page 37)

Section ‘How to Configure a Chroma Key Based on an Area Selected on the

Playfield (page 38)

A

VAILABLE

C

OMMANDS

The following table describes the various commands and parameters available on
the chroma key edit screen on the Remote Panel:

Field area or button

Description

Chroma Key
Parameters (F1-F7)

Parameters to define the color range taken into account
in the chroma key definition.

For more information on the various parameters, refer the
section ‘Chroma Key Parameters’, on page 31.

Toggle View (F8)

Toggles between the key layer view (white & black), and
image view (color) on the operator’s PGM monitor.

Auto (SHIFT+A)

Press this key to perform an automatic chroma key
definition that you can then save in one of the available
profiles.

Save (SHIFT+B)

Press this key to save the changes into the currently

loaded profile (highlighted in black on the Chroma Key
edit screen.

33
