Issue 5.8.B IPDirector Version 5.8 – User Manual – Part 3 – Browsing
EVS Broadcast Equipment – July 2010
58
5.2 CLIP ELEMENTS TREE STRUCTURE
Like the Clips branch, the Clip Elements tree structure of IPDirector, makes the
following sub-branches available:
• XNet, i.e. physical hardware present on the XNet, such as:
o
hi-res EVS video servers: displays XT hi-res-clips saved on the hi-res EVS
video servers.
o
lo-res EVS video servers: displays XT lo-res-clips saved on the lo-res EVS
video servers
o
XF[2] or XStore hosting XFile software: displays clips which have been
backed up to XFile and then published from XFile to the XNet
Note
Even if an XT clip is backed up to XFile in a file format, when the
file is published from XFile, it appears as ‘XT type’ element in the
Database Explorer grid.
