3G SLSM 2x-3x Configurations
The 3G SLSM 2x-3x configurations are valid with all HD codecs natively supported by the
EVS server in the following conditions:
• The server is equipped with V3X boards.
• The license code 110 (Super Motion) is valid.
• The base configuration is Multicam LSM.
• The parameter 3G/Dual is set to No.
• The resolution must be HD 720p or 1080i.
Note
The 3G SLSM configurations are managed via the SLSM REC setting, and not
via the 3G/Dual setting. As the EVS server is operated in HD, this allows the
connection of both a standard HD camera and a 3G SLSM camera at the same
time.
3.2.4. SLSM Configurations
Introduction
SLSM Principles
This section details the available multi-phase SLSM configurations on XT2+ servers.
In SLSM configurations, a supermotion recorder of a two- or three-phase camera accounts
for one logical channel, but corresponds respectively to two or three physical channels.
In 3G SLSM configurations, a supermotion recorder of a two-phase camera corresponds
to one logical channel, and is cabled on the primary link of a codec module. It however
uses both primary and secondary links of that codec module on the V3X board.
Overview on Configurations
The tables in the following sections show the available SLSM configurations with an XT2+
6U server, and how the BNC connectors should be cabled.
Note
Specific SLSM configurations for 1080p/3D dual link and 3G configurations are
presented in the section "3D/1080p SLSM Configurations" on page 72.
