16 | English
1 609 92A 01V | (20.12.12) Bosch Power Tools
Product Features
The numbering of the product features refers to the illustra-
tion of the radio charger on the graphics page.
1 Speaker
2 Remote control
3 Carrying handle
4 Control lamp for A/C supply
(not for article number 3 601 D29 660)
5 A/C outlet cover
(not for article number 3 601 D29 660)
6 A/C socket outlet
(not for article number 3 601 D29 660)
7 “|<<” button on the remote control
8 Outlet opening for infra-red beam
9 Increase volume button
10 “>>|” button on the remote control
11 Play/pause button on the remote control
12 Reduce volume button
13 On/Off button for audio operation on the remote control
14 “Source” button for audio source on the remote control
15 “Mute” button
16 Loop-clip button
17 Latch of back-up battery lid
18 Back-up battery lid
19 Locking latch of digital media bay flap
20 Digital media bay flap
21 Rod antenna
22 Charging compartment
23 Locking latch of battery lid
24 Battery lid
25 Battery pack*
26 “Equalizer” button
27 “Memory ” button
28 “Custom” button (for manual sound adjustment)
29 “Clock” button (for setting the time)
30 “Tune” adjustment knob (for tuning of stations)
31 Reception lens for remote control
32 Button for random playback/repeat
33 “Seek +/>>|” button
34 “Source” button (for selecting an audio source)
35 “|< button
36 Play/pause button
37 Adjustment knob for volume level (“Volume”) and
sound (“Bass/Treb”)
38 On/Off button for audio operation
39 Display
40 “AUX 1 IN” socket
41 12 V connection socket
42 “LINE OUT” socket
43 Fuse cap
44 Fuse for 12 V connection
45 USB port
46 SD/MMC slot
47 “AUX 2 IN” socket
48 Holder for external audio sources
*Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
Display elements for audio operation
a Equalizer (sound-pre-set) indicator
b Changing treble – indicator
c Changing bass – indicator
d Indicator for volume, memory location for radio station
and title (depends on the selected audio source)
e Station-memory reception indicator
(for radio operation)
f Random playback indicator (for SD/MMC card or USB
audio source)
g Repeat-current-track indicator for all tracks in the cur-
rent folder/directory (for SD/MMC card or USB audio
source)
h Repeat-current-track indicator (for SD/MMC card or
USB audio source)
i Stereo indicator
j Indicator of radio frequency/Play duration of current
track (depends on the selected audio source)
k Temperature warning
l Battery inserted indicator
m Battery charge indicator
n Audio-source indicator
o Time indication display
Technical Data
Radio Charger GML 50
Article number 3 601 D29 6..
Back-up batteries 2 x 1,5 V (LR06/AA)
Operating temperature °C 0...45
Storage temperature °C –20...+70
Weight according to EPTA-Procedure 01/2003 kg 11.2
Protection class / I
Degree of protection IP 54 (dust and splash water protected)
1) (for SD/MMC card or USB audio source)
2) The working range can be decreased by unfavourable environmental conditions (e.g. direct sun irradiation).
