8.8 FLIGHT DATA LOGGING
The flight data logging feature automatically stores flight and engine data to an SD card (4 GB maximum card
size) inserted into the top card slot of the MFD. Data is recorded to the SD card every second. One hour of flight
data requires approximately 2 MB of storage space. A 2 GB SD card will store over 1,000 hours of flight data.
It is best to use an SD card that contains no other files. If necessary, reformat the SD card before use as a flight
data logging card. The data files stored on the SD card have an extension of .csv. This file format can be opened
using a spread sheet application on a personal computer.
The following is a list of the types of data recorded. Not all data types are applicable to all aircraft. For example,
EGT and CHT would not apply to turbine aircraft.
• Local Date (YYYY-MM-DD)
• Local Time (HH:MM:SS)
• Active Waypoint Distance (nm)
• Active Waypoint Bearing (degrees mag.)
• UTC Offset (HH:MM)
• Mag. Variation (degrees)
• Active Waypoint Identifier
• Voltage 1 (volts)
• Voltage 2 (volts)
• Amps 1 (amps)
• Amps 2 (amps)
• AFCS On ( 0 – false, 1 – true)
• Latitude (degrees)
• AFCS Roll Mode (e.g. HDG, LOC, GPS, VOR, ROL)
• Longitude (degrees)
• Right Fuel Qty (gals or lbs)
• Left Fuel Qty (gals or lbs)
• Center Fuel Qty (gals or lbs)
• AFCS Pitch Mode (e.g. ALT, GS, GP, VS)
• Barometric Altitude (feet)
• Altimeter Setting (in. Hg.)
• GPS Altitude (ft)
• Pitch Commanded (degrees)
• Roll Commanded (degrees)
• OAT (deg. C)
• True Airspeed (kts)
• Selected Vertical Speed (fpm)
• Vertical Speed (fpm)
• HSI Selection (GPS,NAV1/2)
• GPS Fix (e.g. 2D, 3D, 3DDiff)
• Indicated Airspeed (kts)
• Horizontal Alert Limit (HAL, meters)
• Gnd Speed (kts)
• Vertical Alert Limit (VAL, meters)
• Vertical Speed (fpm)
• NAV1 Frequency (MHz)
• NAV2 Frequency (MHz)
• Horizontal Protection Level (HPLWAS, meters)
• Pitch (degrees)
• Roll (degrees)
• Horizontal Protection Level (HPLFD, meters)
• Vertical Protection Level (VPLWAS, meters)
• COM1 Frequency (MHz)
• COM2 Frequency (MHz)
• Lateral Acceleration (g)
• CDI Deflection (0.0 to 1.0)
• VDI Deflection (0.0 to 1.0)
• Normal Acceleration (g)
