190-00709-02 Rev. B Garmin G1000 Pilot’s Guide for the Socata TBM 850 37
SYSTEM OVERVIEW
SY
STEM
O
VER
VIEW
FLIGHT
INSTRUMENTS
EAS
AUDIO P
ANEL
& CNS
FLIGHT
MANA
GEMENT
HAZARD
AV
OID
ANCE
AFCS
ADDITIONAL
FEA
TURES
APPENDICES
INDEX
D
isPlay
U
nits
The Display Units Box on the System Setup Page allows configuration of the measurement units used for
the following displayed data:
• Nav angle (magnetic, true)
Affects the BRG field in the PFD Navigation Status Box.
Affects the BRG, DTK, TKE, TRK, and XTK fields in the MFD Navigation Status Box.
When set to ‘AUTO’, magnetic variation is figured into the displayed value. When ‘TRUE’ is selected,
no magnetic variation is calculated and a ‘T’ is displayed next to the value.
• Distance and speed (metric, nautical)
Affects the DIS field in the PFD Navigation Status Box and the range setting of the Inset Map.
Affects all distance and speed displays on the MFD with the exception of the displayed wind speed
displayed on the Navigation Map Page. Wind speed is affected on the Trip Planning Page.
• Altitude and vertical speed (feet, meters)
Affects the Altitude and Vertical Speed References in the AFCS Status Box on the PFD.
Affects all altitude and elevation displays on the MFD, with the exception of VNAV altitudes on the
Active Flight Plan Page.
• Barometric pressure (inches of mercury, hectopascals)
Affects the altimeter setting on the PFD and the pressure display on the Trip Planning Page.
• Temperature (Celsius, Fahrenheit)
Affects all temperature displays on the PFD.
Affects the temperature display on the Trip Planning Page. Does not affect the Engine Indicating
System display.
• Fuel and fuel flow (gallons, imperial gallons, liters, pounds, kilograms)
Affects all fuel and fuel flow displays.
• Weight (pounds, kilograms)
Affects aircraft weights on the Weight Planning Page.
• Position (HDDD°MM.MM’, HDDD°MM’SS.S”, MGRS, UTM/UPS)
Affects all position displays.
To change a Display Units setting:
1) While on the System Setup Page, press the FMS Knob momentarily to activate the flashing cursor.
2) Turn the large FMS Knob to highlight the desired field in the Display Units Box.
3) Turn the small FMS Knob to select from a list of measurement units and press the ENT Key when the desired
unit is highlighted. Press the CLR Key to cancel the action without changing the units.
