Garmin G1000 Pilot’s Guide for the Socata TBM 850 190-00709-02 Rev. B 322
HAZARD AVOIDANCE
SY
STEM
O
VER
VIEW
FLIGHT
INSTRUMENTS
EAS
AUDIO P
ANEL
& CNS
FLIGHT
MANA
GEMENT
HAZARD
AV
OID
ANCE
AFCS
ADDITIONAL FEA
TURES
APPENDICES
INDEX
SURFACE ANALYSIS AND CITY FORECAST
NOTE: Surface Analysis and City Forecast data are displayed only within the installed Aviation Database
service area.
Surface Analysis and City Forecast information (Figure 6-27) is available for current and forecast weather
conditions. Forecasts are available for intervals of 12, 24, 36, and 48 hours.
Figure 6-27 Surface Analysis Data - 36-Hour
Displaying Surface Analysis and City Forecast information:
1) Select the Weather Data Link Page with the FMS Knob.
2) Select the MORE WX Softkey.
3) Select the SFC Softkey.
4) Select the forecast time: CURRENT, 12 HR, 24 HR, 36 HR, or 48 HR. The SFC Softkey label changes to reflect
the forecast time selected.
