• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • 4 – 23
Diagnostic Menu
4
3.
=====================
Ready to record.
Press Enter
to start recording.
Press BACK To Exit.
Record Data
Press ENTER to start
recording.
✓
=====================
Collecting data for
frame # xx
Press ENTER to end
recording
Recording
Data continues to be saved until
either:
❒ Record memory is full.
❒ Operator presses ENTER.
✓
Scan Tool recording times vary. A recording consists of frames of data
prior to trigger and several frames after trigger.
4.
=====================
Playback data?
NO
Record Data
YES YES
After recording, Scan Tool
displays a prompt to
Playback Data.
• Answer No to return to
Diagnostic Menu.
•Answer Yes to display
recorded data.
❒ Refer to “Recording” for
instructions on how to
Playback Data.
