Using The Scan Tool
3
Recording
The Recording function is used to play back a recording.
✓
This function is very similar to View Data. The only difference is that
View Data is real time viewing of PIDs, while Recording is a viewing
of previously recorded PIDs.
From the Review Data menu:
1.Select
Recording.
•Use UP or
DOWN
arrow key until Recording is
highlighted.
2.
Select Playback Recording.
✓
The Recording has frame
number and timestamp (in
seconds).
❒ Negative frames and
timestamps indicate data
recorded before trigger event.
❒ Positive frames and
timestamps indicate data
recorded after trigger event.
❒ Use UP or
DOWN
arrow keys to view recorded PID data
of each frame.
❒ Use
LEFT
or RIGHT arrow keys to scroll back and forth
through frames.
❒ See Appendix A for PID Definitions.
=====================
I/M Monitors
DTCs (Codes)
State OBD Check
View Fre eze Data
02 Monitor Tests
Review Data
Recording
=====================
English
Long PID Names
English/Metric
Playback Options
Playback Recording
ON MIL STATUS
ABSLT TPS(%) 100
ENGINE SPEED(RPM) 688
CALC LOAD(%) 0
MAP ("HG) 30.7
FRAME:0 TM 0.0
Throttle Position
