Diagnostic Menu
4
✓
Selected PIDs are kept until you exit View Data and return to the
Diagnostic Menu.
4.
15.5
A/C PRESS (V) 3.00
A/F RATIO
14:1
BARO PRESS ("Hg) 29.9
ABSLT TPS (%) 12.2
ENGINE (RPM) 2352
CALC LOAD (%) 83.1
MAF (LB/M) 0.57
A/C PRESS (psi)
View PIDs on Scan Tool.
•Use UP or DOWN
arrow key.
•See Appendix A for PID
Definitions.
✓
If the icon displays while a PID is selected press ENTER to
view graph. Press BACK key to Return to PID Screen.
5. Return to Select Data to View Menu.
•Press BACK .
6. Return to Diagnostic Menu.
•Press BACK .
Record Data
✓
The Record Data function records PIDs while vehicle is parked or
being driven.
✓
The Record Data function is mainly used for diagnosing intermittent
driveability problems that cannot be isolated by any other method.
✓
The recording time varies. A recording consists of frames of data prior
to the trigger and several frames after the trigger.
! CAUTION
Two people must be in vehicle when driving. One to
drive and the other to operate the Scan Tool.
