Page 53
ACR1283L – Reference Manual
Version 1.00
www.acs.com.hk
Page 53 of 55
Bit7
Bit6
Bit5
Bit4
Scrolling Period
0
1
1
1
23 Units
1
0
0
0
129 Units
1
0
0
1
131 Units
1
0
1
0
133 Units
1
0
1
1
135 Units
1
1
0
0
145 Units
1
1
0
1
147 Units
1
1
1
0
149 Units
1
1
1
1
151 Units
Table 5: Scrolling Period
Bit1
Bit0
Scrolling Direction
0
0
From Left to Right
0
1
From Right to Left
1
0
From Top to Bottom
1
1
From Bottom to Top
Table 6: Scrolling Direction
Where:
Data Out: SW1 SW2
Status Code
Results
SW1 SW2
Meaning
Success
90 00h
The operation is completed successfully.
Error
63 00h
The operation is failed.
5.4.16.6. Pause LCD Scrolling
This command is used to pause the LCD scrolling set before. To resume the scrolling, send again the
scrolling LCD command to perform.
Pause Scrolling Command Format (5 Bytes)
Command
Class
INS
P1
P2
Lc
Pause LCD Scrolling
0xFFh
0x00h
0x6Eh
0x00h
0x00h
Where:
Data Out: SW1 SW2
