5.4.12. Two LEDs Control
This command is used to control the LEDs output.
LED Control Format (6 Bytes)
Command
Class
INS
P1
P2
Lc
Data In
LED Control
0xE0h
0x00h
0x00h 0x29h
0x01h
LED
Status
LED Control Response Format (6 Bytes)
Response
Class
INS
P1
P2
Le
Data Out
Result
0xE1h
0x00h
0x00h
0x00h
0x01h
LED
Status
LED Status (1 Byte)
LED Status
Description
Description
Bit 0
Blue LED
1 = ON; 0 = OFF
Bit 1
Orange LED
1 = ON; 0 = OFF
Bit 2 - 7
RFU
RFU
