ACR1283L – Reference Manual [email protected]
Version 1.00 www.acs.com.hk
Page 28 of 55
bytes).
Example 1: Decimal –4 = {0xFFh, 0xFFh, 0xFFh, 0xFCh}
Value
MSB LSB
FFh FFh FFh FCh
Example 2: Decimal 1 = {0x00h, 0x00h, 0x00h, 0x01h}
Value
MSB LSB
00h 00h 00h 01h
Read Value Block Response Codes
Results SW1 SW2 Meaning
Success 90 00h The operation is completed successfully.
Error 63 00h The operation is failed.
5.3.2.2.7. Copy Value Block
This command is used to copy a value from a value block to another value block.
Copy Value Block APDU Format (7 Bytes)
Command Class INS P1 P2 Lc Data In
Value Block
Operation
FFh D7h 00h
Source Block
Number
02h 03h
Target Block
Number
Where:
Source Block Number (1 Byte): The value of the source value block will be copied to the
target value block.
Target Block Number (1 Byte): The value block to be restored. The source and target value
blocks must be in the same sector.
Copy Value Block Response Format (2 Bytes)
Response Data Out
Result SW1 SW2
Copy Value Block Response Codes
Results SW1 SW2 Meaning
Success 90 00h The operation is completed successfully.
Error 63 00h The operation is failed.
