ACR1283L – Reference Manual [email protected]
Version 1.00 www.acs.com.hk
Page 24 of 55
// To authenticate the Block
0x04h with a {TYPE A, key number 0x00h }.
// PC/SC V2.07
APDU = {FF 86 00 00 05 01 00
04 60 00h }
Note: Mifare Ultralight does not need to do any authentication. The memory is free to access.
Table 4: Mifare Ultralight Memory Map
5.3.2.2.3. Read Binary Blocks
This command is used for retrieving a multiple of “data blocks” from the PICC. The data block/trailer
block must be authenticated first before executing the Read Binary Blocks command.
Read Binary APDU Format (5 Bytes)
Command Class INS P1 P2 Le
Read Binary
Blocks
FFh B0h 00h
Block
Number
Number of Bytes
to Read
Where:
Block Number (1 Byte): The starting block.
Number of Bytes to Read (1 Byte):
Multiply of 16 bytes for MIFARE 1K/4K or Multiply of 4 bytes for Mifare Ultralight
Byte Number 0 1 2 3 Page
Serial Number SN0 SN1 SN2 BCC0 0
Serial Number SN3 SN4 SN5 SN6 1
Internal/Lock BCC1 Internal Lock0 Lock1 2
OTP OPT0 OPT1 OTP2 OTP3 3
Data read/write Data0 Data1 Data2 Data3 4
Data read/write Data4 Data5 Data6 Data7 5
Data read/write Data8 Data9 Data10 Data11 6
Data read/write Data12 Data13 Data14 Data15 7
Data read/write Data16 Data17 Data18 Data19 8
Data read/write Data20 Data21 Data22 Data23 9
Data read/write Data24 Data25 Data26 Data27 10
Data read/write Data28 Data29 Data30 Data31 11
Data read/write Data32 Data33 Data34 Data35 12
Data read/write Data36 Data37 Data38 Data39 13
Data read/write Data40 Data41 Data42 Data43 14
Data read/write Data44 Data45 Data46 Data47 15
512 bits
Or
64 bytes
