Examples:
//
Store a value “1” into block 0x05h
APDU = { FF D7 00 05 05 00 00 00 00 01h}
//
Read the value block 0x05h
APDU = { FF B1 00 05 00h}
//
Copy the value from value block 0x05h to value block 0x06h
APDU = { FF D7 00 05 02 03 06h }
//
Increment the value block 0x05h by “5”
APDU = { FF D7 00 05 05 01 00 00 00 05h}
5.3.2.3. Access PCSC-compliant Tags (ISO 14443-4)
Basically, all ISO 14443-4 compliant cards (PICCs) would understand the ISO 7816-4 APDUs. The
ACR1283L reader has to communicate with the ISO 14443-4 compliant cards through exchanging
ISO 7816-4 APDUs and responses. ACR1283L handles the ISO 14443 Parts 1-4 Protocols internally.
Mifare 1K, 4K, MINI and Ultralight tags are supported through the T=CL emulation. Simply treat the
Mifare tags as standard ISO 14443-4 tags.
ISO 7816-4 APDU Format
Command Class INS P1 P2 Lc Data In Le
ISO 7816 Part
4 Command
Length of
the Data In
Expected length
of the Response
Data
ISO 7816-4 Response Format (Data + 2 Bytes)
Response Data Out
Result Response Data SW1 SW2
Common ISO 7816-4 Response Codes
Results SW1 SW2 Meaning
Success 90 00h The operation is completed successfully.
Error 63 00h The operation is failed.
Typical sequence may be:
1. Present the Tag and Connect the PICC Interface.
2. Read/Update the memory of the tag.
