Table 2 : mifare 1k memory map, Table 3 : mifare 4k memory map – ACS ACR1283L User Manual
Page 23
ACR1283L – Reference Manual
Version 1.00
www.acs.com.hk
Page 23 of 55
Sectors
(Total 16 sectors. Each
sector consists of 4
consecutive blocks)
Data Blocks
(3 blocks, 16 bytes
per block)
Trailer Block
(1 block, 16 bytes)
Sector 0
0x00h ~ 0x02h
0x03h
Sector 1
0x04h ~ 0x06h
0x07h
..
..
Sector 14
0x38h ~ 0x0Ah
0x3Bh
Sector 15
0x3Ch ~ 0x3Eh
0x3Fh
Table 2: Mifare 1K Memory Map
Sectors
(Total 32 sectors. Each
sector consists of 4
consecutive blocks)
Data Blocks
(3 blocks, 16 bytes per
block)
Trailer Block
(1 block, 16 bytes)
Sector 0
0x00h ~ 0x02h
0x03h
Sector 1
0x04h ~ 0x06h
0x07h
..
..
Sector 30
0x78h ~ 0x7Ah
0x7Bh
Sector 31
0x7Ch ~ 0x7Eh
0x7Fh
Sectors
(Total 8 sectors. Each
sector consists of 16
consecutive blocks)
Data Blocks
(15 blocks, 16 bytes
per block)
Trailer Block
(1 block, 16 bytes)
Sector 32
0x80h ~ 0x8Eh
0x8Fh
Sector 33
0x90h ~ 0x9Eh
0x9Fh
..
..
Sector 38
0xE0h ~ 0xEEh
0xEFh
Sector 39
0xF0h ~ 0xFEh
0xFF
Table 3: Mifare 4K Memory Map
Examples:
// To authenticate the Block
0x04h
with a {TYPE A, key number
0x00h
}.
// PC/SC V2.01, Obsolete
APDU = {FF 88 00 0
4
60
00h
};
1K
Bytes
2K
Bytes
2K
Bytes
