Miscellaneous
Input Voltage DC 18v
Input Current 1.5A
Anti-static Strength < 15KV
Operational Relative Humidity 10 – 60%
Operational Temperature 0 – 40º C (32 – 104º F)
Storage Relative Humidity 10 – 80%
Storage Temperature -10 – 60º C (14 – 140º F)
Dimensions (Clock) 197 (w) x 239 (h) x 133 (d) mm
Dimensions (Box) 266 (w) x 283 (h) x 208 (d) mm
Weight (Clock Only) 4.3 Lbs.
Weight (Boxed) 4.5 Lbs.
Time Card Dimension 190 – 192mm x 85-85.5mm
Time Card Weight 300g
Circuit Board Batteries (2) CR2032 (2 yr life)
Ribbon Life
The ATR242 ribbon (39-0135-000) will typically last 3 months with 50 employees
punching 6 times per day (~18,000 punches). Actual ribbon life will vary based on
the number of punches, humidity, temperature and exposure to air.
Operational Battery Pack
The optional Operational Battery Pack (58-0114-000) is a 12 cell NiMH (Nickel
Metal Hydride) battery pack that recharges when the ATR360 is plugged in. In the
event of a power failure the clock will instantly switch to battery power without any
interruption in service. The operational battery pack allows for full operation of the
clock with punching using the fingerprint reader or Prox badge. The clock will also
continue to print on time cards. The LCD backlight is not activated when the clock
is running on battery power in order to save power, however, the LCD display is
plainly visible in a lighted room.
Battery Pack Specs:
Voltage: DC 14.4v
Capacity: 1800mA
Standby mode: 30-36hr reserve power
Fully charged: 5 days use (300 punches/day)
Note: Actual battery life depends on many factors such as battery age, temperature,
discharge history, etc., and can vary greatly depending on these factors.
The ATR360 should be plugged in for 12 hours to fully charge the battery pack.
For more information see “Installing the Operational Battery Pack” in the Appendix.
