Acroprint ESP180 Time Stamp - Manual

ESP180
Quick
Start
Wall Mount Bracket
Keyhole
Back of ESP180
Unpacking and inspection
Open the shipping carton and carefully remove
the contents:
• ESP180 • 2 keys
• Power cable • Ribbon
• User Manual • 3 screws
ì
M
O 16
AM
Print Bar
(press anywhere)
Ribbon
Access Door
Day of Week
Date
Time
Digital Display
Note: This is the normal display in the
idle prompt. Your display may appear
different based on the settings you
chose when programming the clock.
AM or PM
Card Shelf
Connecting power
The ESP180 may be wall-mounted or placed on a table or
desktop. Before installing the ESP180, connect the power
cord. Before connecting the power cord, you must remove the
wall-mounting bracket on the back of the unit:
1. Use the key to unlock the bracket from the bottom.
2. Insert the key into the keyhole on the bottom.
3. Turn it 1/4 turn counterclockwise.
4. Slide the bracket down and away from the unit.
5. Remove the key.
The power cable is inserted into the recessed area on the
bottom of the clock. Push the cable into the convertor in the
clock until the connector is snug.
Install the bracket, being careful not to pinch the power cord.
í
Key Holder
Card Stop
