Getting To Know Your WorkCentre
1 Paper tray with extension
2 Control
panel
3 Paper output support
4 Front
door
5 Front door latch (2)
6 Paper release lever
7 Parallel Cable Port (XE80
and XE82 only. Use only
cables labeled IEEE-1284)
8 Power cord socket
9 Power switch (on side)
10 Starter-Toner cartridge
11 Drum cartridge
9
8
10
11
1
3
4
2
5
6
7
