Yamaha 9000 Pro - Manual (Page 236)

MIDI Data Format/MIDI-Datenformat/Format de données MIDI MIDI Data Format/MIDI-Datenformat/Format de données MIDI
236 Appendix/Anhang/Annexe
2 1 40 2 00-7F VARIATION TYPE MSB o Refer to the MIDI EFFECT MAP 05(=DELAY L,C,R)
00-7F VARIATION TYPE LSB 00 : basic type 00
42 2 00-7F VARIATION PARAMETER 1 MSB o Refer to the MIDI EFFECT PARAMETER LIST depends on variation type
00-7F VARIATION PARAMETER 1 LSB Refer to the MIDI EFFECT PARAMETER LIST depends on variation type
44 2 00-7F VARIATION PARAMETER 2 MSB o Refer to the MIDI EFFECT PARAMETER LIST depends on variation type
00-7F VARIATION PARAMETER 2 LSB Refer to the MIDI EFFECT PARAMETER LIST depends on variation type
46 2 00-7F VARIATION PARAMETER 3 MSB o Refer to the MIDI EFFECT PARAMETER LIST depends on variation type
00-7F VARIATION PARAMETER 3 LSB Refer to the MIDI EFFECT PARAMETER LIST depends on variation type
48 2 00-7F VARIATION PARAMETER 4 MSB o Refer to the MIDI EFFECT PARAMETER LIST depends on variation type
00-7F VARIATION PARAMETER 4 LSB Refer to the MIDI EFFECT PARAMETER LIST depends on variation type
4A 2 00-7F VARIATION PARAMETER 5 MSB o Refer to the MIDI EFFECT PARAMETER LIST depends on variation type
00-7F VARIATION PARAMETER 5 LSB Refer to the MIDI EFFECT PARAMETER LIST depends on variation type
4C 2 00-7F VARIATION PARAMETER 6 MSB o Refer to the MIDI EFFECT PARAMETER LIST depends on variation type
00-7F VARIATION PARAMETER 6 LSB Refer to the MIDI EFFECT PARAMETER LIST depends on variation type
4E 2 00-7F VARIATION PARAMETER 7 MSB o Refer to the MIDI EFFECT PARAMETER LIST depends on variation type
00-7F VARIATION PARAMETER 7 LSB Refer to the MIDI EFFECT PARAMETER LIST depends on variation type
50 2 00-7F VARIATION PARAMETER 8 MSB o Refer to the MIDI EFFECT PARAMETER LIST depends on variation type
00-7F VARIATION PARAMETER 8 LSB Refer to the MIDI EFFECT PARAMETER LIST depends on variation type
52 2 00-7F VARIATION PARAMETER 9 MSB o Refer to the MIDI EFFECT PARAMETER LIST depends on variation type
00-7F VARIATION PARAMETER 9 LSB Refer to the MIDI EFFECT PARAMETER LIST depends on variation type
54 2 00-7F VARIATION PARAMETER 10 MSB o Refer to the MIDI EFFECT PARAMETER LIST depends on variation type
00-7F VARIATION PARAMETER 10 LSB Refer to the MIDI EFFECT PARAMETER LIST depends on variation type
56 1 00-7F VARIATION RETURN o - ∞dB...0dB...+6dB(0...64...127) 40
57 1 01-7F VARIATION PAN o L63...C...R63(1...64...127) 40
58 1 00-7F SEND VARIATION TO REVERB o - ∞dB...0dB...+6dB(0...64...127) 00
59 1 00-7F SEND VARIATION TO CHORUS o - ∞dB...0dB...+6dB(0...64...127) 00
5A 1 00-01 VARIATION CONNECTION o 0:INSERTION,1:SYSTEM 00
5B 1 00-7F VARIATION PART o Part1...16(0...15) 7F
AD1(64)
OFF(16...63, 65...127)
5C 1 MW VARIATION CONTROL DEPTH o -64 - +63 40
5D 1 BEND VARIATION CONTROL DEPTH o -64 - +63 40
5E 1 CAT VARIATION CONTROL DEPTH o -64 - +63 40
5F 1 AC1 VARIATION CONTROL DEPTH x -64 - +63 40
60 1 AC2 VARIATION CONTROL DEPTH x -64 - +63 40
TOTAL SIZE 21
2 1 70 1 00-7F VARIATION PARAMETER 11 o Refer to the MIDI EFFECT PARAMETER LIST depends on variation type
71 1 00-7F VARIATION PARAMETER 12 o Refer to the MIDI EFFECT PARAMETER LIST depends on variation type
72 1 00-7F VARIATION PARAMETER 13 o Refer to the MIDI EFFECT PARAMETER LIST depends on variation type
73 1 00-7F VARIATION PARAMETER 14 o Refer to the MIDI EFFECT PARAMETER LIST depends on variation type
74 1 00-7F VARIATION PARAMETER 15 o Refer to the MIDI EFFECT PARAMETER LIST depends on variation type
75 1 00-7F VARIATION PARAMETER 16 o Refer to the MIDI EFFECT PARAMETER LIST depends on variation type
TOTAL SIZE 6
MIDI PARAMETER CHANGE TABLE (MASTER EQ)Address(H)Size(H)Data(H)ParameterRecognizedDescriptionDefault
value(H)2400100 - 04EQ typeo0:FLAT01:JAZZ2:POPS3:ROCK4:CLASSIC1134 -4CEQ gain1o-12 - +12[dB]402104-28EQ frequency1o32-2000[Hz]0C3101-78EQ Q1o0.1-12.074100-01EQ shape1o00:shelving, 01:peaking05134 -4CEQ gain2o-12 - +12[dB]40610E-36EQ frequency2o100-10.0[kHz]1C7101-78EQ Q2o0.1-12.0781not usedx9134 -4CEQ gain3o-12 - +12[dB]400A10E-36EQ frequency3o100-10.0[kHz]220B101-78EQ Q3o0.1-12.070C1not usedx0D134 -4CEQ gain4o-12 - +12[dB]400E10E-36EQ frequency4o100-10.0[kHz]2E0F101-78EQ Q4o0.1-12.07101not usedx11134 -4CEQ gain5o-12 - +12[dB]401211C-3AEQ frequency5o0.5-16.0[kHz]3413101-78EQ Q5o0.1-12.0714100-01EQ shape5o00:shelving, 01:peaking0TOTAL SIZE15 MIDI PARAMETER CHANGE TABLE (EFFECT 2)Address(H)Size(H)Data(H)ParameterRecognizedDescriptionDefault30n0200-7FINSERTION EFFECT n TYPE MSBoRefer to the MIDI EFFECT MAP49(=DISTORTION)00-7FINSERTION EFFECT n TYPE LSB00 : basic type002100-7FINSERTION EFFECT n PARAMETER1oRefer to the MIDI EFFECT PARAMETER LISTdepends on insertion 1
type3100-7FINSERTION EFFECT n PARAMETER2oRefer to the MIDI EFFECT PARAMETER LISTdepends on insertion 1
type4100-7FINSERTION EFFECT n PARAMETER3oRefer to the MIDI EFFECT PARAMETER LISTdepends on insertion 1
type5100-7FINSERTION EFFECT n PARAMETER4oRefer to the MIDI EFFECT PARAMETER LISTdepends on insertion 1
type610 Pages: 1 … 234 235 236 237 238 … 250 wrong Brand wrong Model non readable See also other documents in the category Yamaha The input devices: PORTABLE GRAND DGX-200 (100 pages) Portatone PSR-8 (28 pages) Portasound PC-50 (24 pages) L-140S (2 pages) disklavier Mark II XG Series (14 pages) PortaSound PSS-21 (14 pages) PSR-150 (26 pages) MOTIF XS6/7/8 (7 pages) CLAVINOVA CVP-505 (138 pages) Portable Grand PortableGrand DGX-203 (98 pages) Portatone EZ-250i (87 pages) HandySound HS-501 (12 pages) Clavinova CLP-153S (29 pages) Portable Grand PSR-293 (98 pages) Clavinova CLP-20 (11 pages) Pedal Unit LP-7/LP-5 (2 pages) Modus H11 (2 pages) DGX-520 (142 pages) Portatone PSR-3 (12 pages) DGX-305 (112 pages) Personal Electronic Piano YPP-15 (20 pages) Portatone PSR-100 (12 pages) CLAVINOVA CVP-501 (104 pages) DJX (120 pages) Clavinova CLP-560 (28 pages) PORTATONE PSR-2000 (172 pages) J-5000 (60 pages) Clavinova CVP-5 (22 pages) Portatone PSR-22 (20 pages) YFP-70 (27 pages) Digital piano YDP-223 (72 pages) Clavinova CLP-250 (17 pages) CLP-110 (46 pages) Clavinova CLP-100 (11 pages) PORTATONE PSR-293 (98 pages) high-quality stereo amplifier/speaker system PSR-140 (52 pages) YPT-230 (48 pages) PORTATONE PSR-140 (52 pages) Pedal Unit LP-7A/LP-5A (2 pages) PLG100-VH (32 pages) PortaSound PSS-80 (16 pages) L-2L (1 page) Portatone PSR-E213 (72 pages) Clavinova CLP-50 (11 pages) Sitemap
Address
(H)
Size
(H)
Data
(H)
Parameter Recognized Description Default
value(H)
2 40 0 1 00 - 04 EQ type o 0:FLAT 0
1:JAZZ
2:POPS
3:ROCK
4:CLASSIC
1 1 34 -4C EQ gain1 o -12 - +12[dB] 40
2 1 04-28 EQ frequency1 o 32-2000[Hz] 0C
3 1 01-78 EQ Q1 o 0.1-12.0 7
4 1 00-01 EQ shape1 o 00:shelving, 01:peaking 0
5 1 34 -4C EQ gain2 o -12 - +12[dB] 40
6 1 0E-36 EQ frequency2 o 100-10.0[kHz] 1C
7 1 01-78 EQ Q2 o 0.1-12.0 7
8 1 not used x
9 1 34 -4C EQ gain3 o -12 - +12[dB] 40
0A 1 0E-36 EQ frequency3 o 100-10.0[kHz] 22
0B 1 01-78 EQ Q3 o 0.1-12.0 7
0C 1 not used x
0D 1 34 -4C EQ gain4 o -12 - +12[dB] 40
0E 1 0E-36 EQ frequency4 o 100-10.0[kHz] 2E
0F 1 01-78 EQ Q4 o 0.1-12.0 7
10 1 not used x
11 1 34 -4C EQ gain5 o -12 - +12[dB] 40
12 1 1C-3A EQ frequency5 o 0.5-16.0[kHz] 34
13 1 01-78 EQ Q5 o 0.1-12.0 7
14 1 00-01 EQ shape5 o 00:shelving, 01:peaking 0
TOTAL SIZE 15
Address
(H)
Size
(H)
Data
(H)
Parameter Recognized Description Default
3 0n 0 2 00-7F INSERTION EFFECT n TYPE MSB o Refer to the MIDI EFFECT MAP 49(=DISTORTION)
00-7F INSERTION EFFECT n TYPE LSB 00 : basic type 00
2 1 00-7F INSERTION EFFECT n PARAMETER1 o Refer to the MIDI EFFECT PARAMETER LIST depends on insertion 1
type
3 1 00-7F INSERTION EFFECT n PARAMETER2 o Refer to the MIDI EFFECT PARAMETER LIST depends on insertion 1
type
4 1 00-7F INSERTION EFFECT n PARAMETER3 o Refer to the MIDI EFFECT PARAMETER LIST depends on insertion 1
type
5 1 00-7F INSERTION EFFECT n PARAMETER4 o Refer to the MIDI EFFECT PARAMETER LIST depends on insertion 1
type
610
