Yamaha 9000 Pro - Manual (Page 222)

Effect Parameter List/Effektparameterliste/
222 Appendix/Anhang/Annexe
Effect Parameter List/Effektparameterliste/
XG Effect Name TypeMSB (Type LSB)
HALL1,HALL2 MSB = 01
ROOM1,ROOM2,ROOM3 MSB = 02
STAGE1,STAGE2 MSB = 03
PLATE (reverb, variation, insertion block) MSB = 04
DELAY L,C,R (variation, insertion block) MSB = 05
DELAY L,R (variation, insertion block) MSB = 06
ECHO (variation, insertion block) MSB = 07
CROSS DELAY (variation, insertion block) MSB = 08
EARLY REF1,EARLY REF2(variation, Insertion1-4 block) MSB = 09
GATE REVERB MSB = 10
REVERSE GATE (variation, Insertion1-4 block) MSB = 11
WHITE ROOM MSB = 16
TUNNEL MSB = 17
CANYON MSB = 18
BASEMENT (reverb, variation, Insertion1-4 block) MSB = 19
KARAOKE1,2,3 (variation, insertion block) MSB = 20
TEMPO DELAY (variation, Insertion block)
TEMPO ECHO (variation, Insertion block)
MSB = 21
TEMPO CROSS (variation, Insertion block) MSB = 22
No. Parameter Display Value See Table Control
1 Reverb Time 0.3~30.0s 0-69 table#4
2 Diffusion 0~10 0-10
3 Initial Delay 0.1mS~99.3mS 0-63 table#5
4 HPF Cutoff Thru~8.0kHz 0-52 table#3
5 LPF Cutoff 1.0k~Thru 34-60 table#3
6
7
8
9
10 Dry/Wet D63>W ~ D=W ~ D 1-127 ●
11 Rev Delay 0.1mS~99.3mS 0-63 table#5
12 Density 0~4 (reverb, variation, insertion 1~4 block) 0-4
0~2 (insertion 5 block) 0-2
13 Er/Rev Balance E63>R ~ E=R ~ E 1-127
14 High Damp 0.1~1.0 1-10
15 Feedback Level -63~+63 1-127
16
No. Parameter Display Value See Table Control
1 Lch Delay 0.1~1.4860s (variation block) 1-14860
0.1~1.4860s (Insertion block) 1-14860
2 Rch Delay 0.1~1.4860s (variation block) 1-14860
0.1~1.4860s (Insertion block) 1-14860
3 Cch Delay 0.1~1.4860s (variation block) 1-14860
0.1~1.4860s (Insertion block) 1-14860
4 Feedback Delay 0.1~1.4860s (variation block) 1-14860
0.1~1.4860s (Insertion block) 1-14860
5 Feedback Level -63~+63 1-127
6 Cch Level 0~127 0-127
7 High Damp 0.1~1.0 1-10
8
9
10 Dry/Wet D63>W ~ D=W ~ D 1-127 ●
11
12
13
EQ Low Frequency 32Hz~2.0kHz 4-40 table#3
14 EQ Low Gain -12~+12dB 52-76
15 EQ High Frequency 500Hz~16.0kHz 28-58 table#3
16 EQ High Gain -12~+12dB 52-76
No. Parameter Display Value See Table Control
1 Lch Delay 0.1~1.4860s (variation block) 1-14860
0.1~1.4860s (Insertion block) 1-14860
2 Rch Delay 0.1~1.4860s (variation block) 1-14860
0.1~1.4860s (Insertion block) 1-14860
3 Feedback Delay 1 0.1~1.4860s (variation block) 1-14860
0.1~1.4860s (Insertion block) 1-14860
4 Feedback Delay 2 0.1~1.4860s (variation block) 1-14860
0.1~1.4860s (Insertion block) 1-14860
5 Feedback Level -63~+63 1-127
6 High Damp 0.1~1.0 1-10
7
8
9
10 Dry/Wet D63>W ~ D=W ~ D 1-127 ●
11
12
13
EQ Low Frequency 32Hz~2.0kHz 4-40 table#3
14 EQ Low Gain -12~+12dB 52-76
15 EQ High Frequency 500Hz~16.0kHz 28-58 table#3
16 EQ High Gain -12~+12dB 52-76
No. Parameter Display Value See Table Control
1 Lch Delay1 0.1~743.0ms (variation block) 1-7430
0.1~743.0ms (insertion block) 1-7430
2 Lch Feedback Level -63~+63 1-127
3 Rch Delay1 0.1~743.0ms (variation block) 1-7430
0.1~743.0ms (insertion block) 1-7430
4 Rch Feedback Level -63~+63 1-127
5 High Damp 0.1~1.0 1-10
6 Lch Delay2 0.1~743.0ms (variation block) 1-7430
0.1~743.0ms (insertion block) 1-7430
7 Rch Delay2 0.1~743.0ms (variation block) 1-7430
0.1~743.0ms (insertion block) 1-7430
8 Delay2 Level 0~127 0-127
9
10 Dry/Wet D63>W ~ D=W ~ D 1-127 ●
11
12
13
EQ Low Frequency 32Hz~2.0kHz 4-40 table#3
14 EQ Low Gain -12~+12dB 52-76
15 EQ High Frequency 500Hz~16.0kHz 28-58 table#3
16 EQ High Gain -12~+12dB 52-76
No. Parameter Display Value See Table Control
1 L->R Delay 0.1~743.0ms (variation block) 1-7430
0.1~743.0ms (insertion block) 1-7430
2 R->L Delay 0.1~743.0ms (variation block) 1-7430
0.1~743.0ms (insertion block) 1-7430
3 Feedback Level -63~+63 1-127
4 Input Select L,R,L&R 0-2
5 High Damp 0.1~1.0 1-10
6
7
8
9
10 Dry/Wet D63>W ~ D=W ~ D 1-127 ●
11
12
13
EQ Low Frequency 32Hz~2.0kHz 4-40 table#3
14 EQ Low Gain -12~+12dB 52-76
15 EQ High Frequency 500Hz~16.0kHz 28-58 table#3
16 EQ High Gain -12~+12dB 52-76
No. Parameter Display Value See Table Control
1 Type S-H, L-H, Rdm, Rvs, Plt, Spr 0-5
2 Room Size 0.1~7.0 0-44 table#6
3 Diffusion 0~10 0-10
4 Initial Delay 0.1mS~200.0mS 0-127 table#5
5 Feedback Level -63~+63 1-127
6 HPF Cutoff Thru~8.0kHz 0-52 table#3
7 LPF Cutoff 1.0k~Thru 34-60 table#3
8
9
10 Dry/Wet D63>W ~ D=W ~ D 1-127 ●
11 Liveness 0~10 0-10
12 Density 0~3 0-3
13 High Damp 0.1~1.0 1-10
14
15
16
No. Parameter Display Value See Table Control
1 Type TypeA,TypeB 0-1
2 Room Size 0.1~7.0 0-44 table#6
3 Diffusion 0~10 0-10
4 Initial Delay 0.1mS~200.0mS 0-127 table#5
5 Feedback Level -63~+63 1-127
6 HPF Cutoff Thru~8.0kHz 0-52 table#3
7 LPF Cutoff 1.0k~Thru 34-60 table#3
8
9
10 Dry/Wet D63>W ~ D=W ~ D 1-127 ●
11 Liveness 0~10 0-10
12 Density 0~3 0-3
13 High Damp 0.1~1.0 1-10
14
15
16
No. Parameter Display Value See Table Control
1 Reverb Time 0.3~30.0s 0-69 table#4
2 Diffusion 0~10 0-10
3 Initial Delay 0.1mS~99.3mS 0-63 table#5
4 HPF Cutoff Thru~8.0kHz 0-52 table#3
5 LPF Cutoff 1.0k~Thru 34-60 table#3
6 Width 0.5~10.2m 0-37 table#11
7 Heigt 0.5~20.2m 0-73 table#11
8 Depth 0.5~30.2m 0-104 table#11
9 Wall Vary 0~30 0-30
10 Dry/Wet D63>W ~ D=W ~ D 1-127 ●
11 Rev Delay 0.1mS~99.3mS 0-63 table#5
12 Density 0~4 0-4
13 Er/Rev Balance E63>R ~ E=R ~ E 1-127
14 High Damp 0.1~1.0 1-10
15 Feedback Level -63~+63 1-127
16
No. Parameter Display Value See Table Control
1 Delay Time 0.1mS~400.0mS 0-127 table#7
2 Feedback Level -63~+63 1-127
3 HPF Cutoff Thru~8.0kHz 0-52 table#3
4 LPF Cutoff 1.0k~Thru 34-60 table#3
5
6
7
8
9
10 Dry/Wet D63>W ~ D=W ~ D 1-127 ●
11
12
13
14
15
16
No. Parameter Display Value See Table Control
1 Delay Time 64th/3 ~ 4thx6 0-19 table#14
2 Feedback Level -63 ~ +63 1-127
3 Feedback High Dump 0 ~ 1.0 0-10
4 L/R Diffusion 1(-63ms)~64(0ms)~127(63ms) 1-127
5 Lag 1(-63ms)~64(0ms)~127(63ms) 1-127
6
7
8
9
10 Dry/Wet D63>W ~ D=W ~ D 1-127 ●
11
12
13
EQ Low Frequency 32~2.0kH 4-40
14 EQ Low Gain -12 ~ +12dB 52-76
15 EQ High Frequency 500 ~ 16.0kHz 28-58
16 EQ High Gain -12 ~ +12dB 52-76
No. Parameter Display Value See Table Control
1 Delay Time L>R 64th/3 ~ 4thx6 0-19 table#14
2 Delay Time R>L 64th/3 ~ 4thx6 0-19 table#14
3 Feedback Level -63 ~ +63 1-127
4 Input Select L, R, L&R 0-2
5 Feedback High Dump 0 ~ 1.0 0-10
6 Lag 1(-63ms)~64(0ms)~127(63ms) 1-127
7
8
9
10 Dry/Wet D63>W ~ D=W ~ D 1-127 ●
11
12
13
EQ Low Frequency 32~2.0kH 4-40
14 EQ Low Gain -12 ~ +12dB 52-76
15 EQ High Frequency 500 ~ 16.0kHz 28-58
16 EQ High Gain -12 ~ +12dB 52-76
