Prestige 642 ADSL Internet Access Router
Bridging Setup 7-3
7.2.1 Remote Node Bridging Setup
Follow the procedure in Chapter 5 to configure the protocol-independent parameters in Menu 11.1 -
Remote Node Profile
. For bridging-specific parameters, you need to configure Menu 11.3 - Remote Node
Network Layer Options .
To set up Menu 11.3 - Remote Node Network Layer Options follow these steps:
Step 1.
In Menu 11.1, make sure the Bridge field is set to Yes.
Step 2. Move the cursor to the Edit IP/IPX/Bridge field, then press the space bar to select Yes and press
[ENTER]
to open Menu 11.3 - Network Layer Options.
Figure 7-2 Menu 11.3 - Remote Node Bridging Options
The following table describes the bridging-specific parameters in the Remote Node Profile and Network
Layers menus.
Table 7-2 P642 Remote Node Network Layers Menu Bridge Options
Field Description
Bridge Make sure this field is set to Yes.
Edit IP/IPX/Bridge Press the space bar to change it to Yes and press ENTER] to go to the
Network Layer Options Menu.
Please note that the following fields are only valid for PPPoE encapsulation.
Dial-On-Broadcast This field is necessary for your Prestige on the caller side LAN. When
set to Yes, any broadcasts coming from the LAN will trigger your
Prestige to make a call to this remote node. If it is set to No, your
Prestige will not make the outgoing call.
Ethernet Addr In this field, enter the time (number of minutes) that you wish your
Menu 11.3 - Remote Node Network Layer Options
VPI/VCI LLC-mux or PPP/PPPoE Encap :
VPI #= 1
VCI #= 1
IP Options :
Rem IP Addr: 0.0.0.0
Rem Subnet Mask= 0.0.0.0
My WAN Addr= 0.0.0.0
Single User Account= No
Metric= 2
Private= No
RIP Direction= Both
Version= RIP-2B
Multicast= None
IP Policies= IPX Options :
Rem LAN Net #= 00000000
My WAN Net #= 00000000
Hop Count= 1
Tick Count= 2
W/D Spoofing(min)= N/A
SAP/RIP Timeout(min)= N/A
Dial-On-Query= N/A
Bridge Options:
Dial-On-Broadcast= N/A
Ethernet Addr Timeout(min)= 0
Enter here to CONFIRM or ESC to CANCEL:
