Prestige 642 ADSL Internet Access Router
IP Policy Routing
11-3
Figure 11-2
Menu 25 - IP Routing Policy Summary
Table 11-1
IP Routing Policy Summary
Abbreviation
Meaning
Criteria
SA
Source IP address
SP
Source port
DA
Destination IP address
DP
Destination port
P
IP layer 4 protocol number(TCP=6,UDP=17…)
T
Type Of Service of Incoming packet
PR
Precedence of incoming packet
Action
GW
Gateway IP address
T
Outgoing Type of Service
P
Outgoing Precedence
Type Of Service
NM
Normal
mD
Minimum Delay
Menu 25.1 - IP Routing Policy Summary
# A Criteria/Action
- - --------------------------------------------------------------------------
1 Y SA=1.1.1.1-1.1.1.1,DA=2.2.2.2-2.2.2.5
SP=20-25,DP=20-25,P=6,T=NM,PR=0 |GW=192.168.1.1,T=MT,PR=0
2 N __________________________________________________________________________
__________________________________________________________________________
3 N __________________________________________________________________________
__________________________________________________________________________
4 N __________________________________________________________________________
__________________________________________________________________________
5 N __________________________________________________________________________
__________________________________________________________________________
6 N __________________________________________________________________________
__________________________________________________________________________
Enter Policy Rule Number (1-6) to Configure:
