Prestige 642 ADSL Internet Access Router
Internet Access 3-7
Remote DHCP
Server If Relay is selected in the DHCP= field above, then enter the IP
address of the actual, remote DHCP server here.
Follow the instructions in the following table to configure TCP/IP parameters for the Ethernet port.
Table 3-2 TCP/IP Ethernet Setup Menu Fields
Field Description Example
TCP/IP Setup
IP Address Enter the (LAN) IP address of your Prestige in dotted decimal
notation
192.168.1.1
(default)
IP Subnet Mask Your Prestige will automatically calculate the subnet mask based on
the IP address that you assign. Unless you are implementing
subnetting, use the subnet mask computed by the Prestige
255.255.255.0
RIP Direction Press the space bar to select the RIP direction from Both/In
Only/Out Only or None.
Both (default)
Version Press the space bar to select the RIP version from RIP-1/RIP-
2B/RIP-2M.
RIP-1 (default)
Multicast IGMP (Internet Group Multicast Protocol) is a session-layer protocol
used to establish membership in a Multicast group. The Prestige
supports both IGMP version 1 (IGMP-v1) and IGMP-v2. Press the
space bar to enable IP Multicasting or select None to disable it.
IGMP-v1
IGMP-v2
None
IP Policies Create policies using SMT Menu 25 (see the IP Policy Routing
chapter in Part 3) and apply them on the Prestige LAN interface
here. You can apply up to four IP Policy sets (from twelve) by
entering their numbers here separated by commas, e.g., 2, 4, 7, 9.
Edit IP Alias The Prestige supports three logical LAN interfaces via its single
physical Ethernet interface with the Prestige itself as the gateway for
each LAN network. Press the space bar to toggle No to Yes, then
press [ENTER] to bring you to menu 3.2.1
Yes
No (default)
When you have completed this menu, press [ENTER] at the prompt [Press ENTER to Confirm…] to save
your configuration, or press [Esc] at any time to cancel.
