Prestige 642 ADSL Internet Access Router
5-2 Remote Node TCP/IP Configuration
Figure 5-2 Menu 11.3 for VC-based multiplexing.
In this case, separate VPI and VCI numbers must be specified for each protocol.
LLC-based multiplexing
For LLC-based multiplexing, one VC may carry different protocols with protocol identifying information
being contained in each packet header.
Figure 5-3 Menu 11.3 for LLC-based multiplexing
Menu 11.3 - Remote Node Network Layer Options
IPX Options:
Rem LAN Net #= N/A
My WAN Net #= N/A
IP Options: Hop Count= N/A
Rem IP Addr: 0.0.0.0 Tick Count= N/A
Rem Subnet Mask= 0.0.0.0 W/D Spoofing(min)= N/A
My WAN Addr= 0.0.0.0 SAP/RIP Timeout(min)= N/A
Single User Account= Yes Dial-On-Query= N/A
Metric= 2 VPI #= N/A
Private= No VCI #= N/A
RIP Direction= None
Version= RIP-1 Bridge Options:
Multicast= None Dial-On-Broadcast= N/A
IP Policies= Ethernet Addr Timeout(min)= N/A
VPI #= 0 VPI #= N/A
VCI #= 35 VCI #= N/A
Enter here to CONFIRM or ESC to CANCEL:
Separate VPI and
VCI numbers must
be specified for
each protocol when
using VC-based
multiplexing as
there must be a
distinct PVC for
each protocol.
Menu 11.3 - Remote Node Network Layer Options
VPI/VCI LLC-mux or PPP/PPPoE Encap :
VPI #= 1
VCI #= 1
IP Options :
Rem IP Addr: 0.0.0.0
Rem Subnet Mask= 0.0.0.0
My WAN Addr= 0.0.0.0
Single User Account= No
Metric= 2
Private= No
RIP Direction= Both
Version= RIP-2B
Multicast= None
IP Policies= IPX Options :
Rem LAN Net #= 00000000
My WAN Net #= 00000000
Hop Count= 1
Tick Count= 2
W/D Spoofing(min)= N/A
SAP/RIP Timeout(min)= N/A
Dial-On-Query= N/A
Bridge Options:
Dial-On-Broadcast= N/A
Ethernet Addr Timeout(min)= 0
Enter here to CONFIRM or ESC to CANCEL:
Only one set of VPI
and VCI numbers
need be specified
as for LLC-based
multiplexing, one
VC may carry
different protocols.
