Prestige 642 ADSL Internet Access Router
IP Policy Routing 11-5
Care].
Source:
addr start= /
end= Source IP address range from start to end.
port start= /
end= Source port number range from start to end; applicable only for TCP/UDP.
Destination:
addr start= /
end= Destination IP address range from start to end.
port start= /
end= Destination port number range from start to end; applicable only for TCP/UDP.
Action= Specifies whether action should be taken on criteria [Matched] or [Not
Matched].
Gateway addr Defines the outgoing gateway address. The gateway must be on the same
subnet as the Prestige if it’s on the LAN, otherwise, the gateway must be the IP
address of a remote node. The default gateway is specified as 0.0.0.0.
Log Press the [SPACEBAR] to select [Yes] to make an entry in the system log when
a policy is executed.
Type of Service Set the new TOS value of the outgoing packet. Choose from Prioritize incoming
network traffic by choosing from [No Change] / [Normal] / [Min Delay] / [Max
Thruput] / [Max Reliability].
Precedence Set the new precedence value of the outgoing packet. Values range from [0] to
[7] or [No Change].
11.2 Applying an IP Policy
This section shows you where to apply the IP Policies after you design them.
11.2.1 Ethernet IP Policies
From Menu 3 - Ethernet Setup, enter 2 to go to Menu 3.2 -General Ethernet Setup.
You can choose up to four IP Policy sets (from twelve) by entering their numbers separated by commas,
e.g., 2, 4, 7, 9.
