Prestige 642 ADSL Internet Access Router
5-4
Remote Node TCP/IP Configuration
Table 5-1
TCP/IP related fields in Remote Node Profile
Field
Description
Option
Route
Make sure IP is among the protocols in the [Route] field in
Menu 11.1 - Remote Node Profile.
IP
Rem IP Address
Enter the IP address of the remote gateway in Menu 11.1 -
Remote Node Profile. You must fill in either the remote
Prestige WAN IP address or the remote Prestige LAN IP
address. This depends on the remote router’s WAN IP i.e., for
the (remote) Prestige, the My WAN Addr settings in Menu
11.3 – Remote Node Network Layer Options). For example
if the remote WAN IP is set to 172.16.0.2 (the remote router’s
WAN IP), then you should enter 172.16.0.2 in the Rem IP
Address field. If the remote WAN IP is 0.0.0.0, then enter
192.168.1.1(the remote router’s LAN IP) in the Rem IP
Address field).
Edit IP
Press the [SPACE BAR] to toggle this field to Yes and then
press [ENTER] to go to Menu 11.3 - Remote Node Network
Layer Options menu.
Yes
(Yes/No)
The following table shows the TCP/IP related fields in Menu 11.3 - Remote Node Network Layer
Options
.
Table 5-2
TCP/IP Remote Node Configuration
Field
Description
Option
VPI
Enter the Virtual Path Identifier (VPI) number that your
telephone company supplies.
VCI
Enter the Virtual Channel Identifier (VCI) number that your
telephone company supplies.
Rem IP Address
This will show the IP address you entered for this remote node in
the previous menu.
Rem IP Subnet
Mask
Enter the subnet mask for the remote network.
My WAN Addr
Some implementations, especially the UNIX derivatives, require
the WAN link to have a separate IP network number from the
LAN and each end must have a unique address within the WAN
network number. If this is the case, enter the IP address
assigned to the WAN port of your Prestige.
Note that this is the address assigned to your local Prestige
WAN, not the remote router. If the remote router is a Prestige,
then this entry determines the local Prestige Rem IP Address in
