CONTROL PANEL
86037580 GLIDE 11/05/08
5-6
REF PART NO.
PRV
NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86270920 57049 2 NUT, 6-32 HEX NYLOCK SS
2 86005550 54183 1 MODULE, LCD
3A 86007190 72161 1 SWITCH, KEY DPST
3B 86004860 48073 REF KEY SERVICE ONLY
4 86007180 72160 1 SWITCH, EMERGENCY STOP
5 86257280 81371 1 SWITCH, PUSH BUTTON
6 86271820 57270 1 NUT, 5/16-18 CAPTIVE “J” PLTD
7 86238000 36216 1 GASKET, .06T X .25W X 26.5L
8 86093320 66364 1 PANEL CONTROL
9 86270990 57090 2 NUT, 10-32 HEX NYLOCK SS
10 86276900 70753 1 SCR, 5/16-18 X 1-1/4 PFHMS SS
11 86003230 27936 1 COVER, FRONT SMALL RIDER
12 86276890 70752 4 SCR, 5/16-18 X 3/4 PTHMS SS
13 86271910 57295 2 NUT, 5/16-18 FLEXLOCK
14 86010670 87029 2 WASHER, 5/16 FLAT SS
15 86068850 140219 2 BRACKET, CABLE ATTACH *(1)
16A 86002660 270070 1 CONTROLLER, GLIDE 28/32
28 IN & 32 IN,
WAS 27950
16B 86002670 270071 1 CONTROLLER, GLIDE 36
36 IN, WAS
27967
16C 86002680 270072 1 CONTROLLER, GLIDE 28/32 GEL
28 IN & 32 IN
WITH SEALED
BATTERIES,
WAS 27972
16D 86027700 270075 1 CONTROLLER, GLIDE 36 GEL
36 IN WITH
SEALED
BATTERIES,
WAS 270009
17 86274410 70195 2 SCR, 10-32 X 1.25 SS
18 86273810 70018 2 SCR, 1/4-20 X 1 HHCS SS
19 86010780 87162 2 WASHER, 1/4 SPLIT LOCK
20 86010630 87013 2 WASHER, 1/4ID X 5/8 OD SS
21 86007520 730142 3 SWITCH, SPDT 3-POSITION MOM
22 86250190 66365 2 PLUG, DD .625-.550
23 86007480 730124 1
SWITCH ASM, SEALED
PUSHBUTTON
24 86007470 730123 1 SWITCH ASM, SEALED PUSH SQ
25 86243510 500563 REF LABEL, CONTROL PANEL
26 86007210 72165 1
SWITCH, DPDT 3-POSITION
ROCKER
36 IN. ONLY
27 86002010 14942 1 BOOT, 3/8 CIRCUIT BREAKER 36 IN. ONLY
28 86001450 140541 1 BREAKER, 2A 250VAC, 50VDC 36 IN. ONLY
29 86271940 57299 1 NUT, 1/4-20 ACORN SS
30 86275760 70540 2 SCR, 5/16-18 X 1 HHCS GR8 PLTD *(1)
*SEE SERIAL NUMBER PAGE.
