Windsor Saber Glide 86037580 - Manual (Page 27)

SCRUB DECK-36 IN MAIN
86037580 GLIDE 01/03/07 5-26
REF PART NO.
PRV
NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86276910 70754 1 SCR, 5/16-18 X 3 HHCS SS NP
2 86001550 40043 2 HOSEBARB, 3/8 MPT X 3/8 90 D
3 86273960 70061 1 SCR, 1/4-20 X 3 HHCS F. THD SS
4 86000840 05171 1 ACTUATOR ASM
5 86005250 53258 2 MOTOR ASM, 36V 330 RPM GEAR
5A 86001890 14418 REF BRUSH SET, MOTOR SERVICE ONLY
6 86223470 67449 2 RING, 20MM EXTERNAL SNAP
7 86271830 57283 2 NUT, 3/8 NPT PLASTIC
8 86253250 730152 2 SHAFT, PIVOT
9 86272620 80670 1 PIN, CLEVIS 1/4 X 1.125 PLTD
10 86007570 730165 1 SPRING, GAS 300 NEWTONS
11 86256500 80649 2 STUD, BALL GAS SPRING
12 86270830 57023 5 NUT, 5/16-18 HEX NYLOCK SS
13 86236170 34277 3 FITTING, 1/2 MPT X 3/8 BARB 90
14 86197910 40022 1 HOSEBARB, 1/2 MPT X 1/2 POLY DL
15 86033220 54185 1 MANIFOLD, SOLUTION FEED SRS
16 86264920 27049 2 CABLE TIE, 7”
17 86281410 39361 2 HOSE, 3/8 NYLOBRAID X 7.5
18 86281480 39390 1 HOSE, 1/2 ID NYLOBRAID X 14”
19 86009200 81535 1 KNOB, 3/8-16 4 PRONG ALUM
20 86274110 70094 1 SCR, 1/4-20 X 1/2 SHCS
21 86010790 87163 8 WASHER, 3/8 SPLIT LOCK
22 86276970 70774 8 SCR, 3/8-16 X 3/4 HHCS
23 86276950 70772 6 SCR, 1/4-20 X 3/4 CARRIAGE SS
24 86007410 730098 1 SKIRT, FRONT 36” DECK
25 86087900 730090 1 STRAP, FRONT SKIRT
26 86005810 57245 8 NUT, 1/4-20 HEX NYLOCK SS
27 86007020 70673 2 SCR, 5/16-18 X 1.25 HHCS SS
28 86279130 87083 2 WASHER, 5/16 SPLIT LOCK PLTD
29 86279630 87212 2 WASHER, .344 ID X 1.13 OD X .09 T
30 86003420 29220 2 DRIVER, BRUSH SD
31 86279530 87173 2 WASHER, .765 ID X 1.31 OD X .09 T SS
32 86093970 730111 1 SCRUB DECK, 36” MIN
33 86087280 730183 1 SPACER, PLATE
34 86008650 80604 1 COTTER, 1/4 RING
35 86087290 730195 4 SPACER, .5OD X .334ID X .860L
36 86082570 62993 2 PLATE, ACTUATOR RETAINER
37 OPEN - -
38 86070300 140610 1 BRKT, ACTUATOR RETAINER
39 86276780 70728 2 SCR, 5/16-18 X 3/4 HHCS SS
