SQUEEGEE LIFT
86037580 GLIDE 01/03/07 5-42
REF PART NO.
PRV
NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86277860 70787 1 SCR, 3/8-16 X 3.75 HHCS SS
2 86010770 87143 3 WASHER, 7/16ID X 1D X .08 FLT SS
3 86010160 82830 1 SPRING, .62 X .09 X 1.6 CS ZC GRND
4 86008870 80815 4 BEARING, FLANGED 3/8” ID 11/16”
5 86008860 80808 2 PIN, CLEVIS 3/8” X 5.5”L PLTD
6 86000810 05167 1 ACTUATOR, 36VDC 2-0 STK
7 86248910 66369 1 PIN, QUICK RELEASE 0.38 X 1.5
8 86008670 80606 3 COTTER, 3/8” RING
9 86255310 73979 2 SPRING, EXT. 1.00OD X 4.0L
10 86272710 82060 1 PIN, CLEVIS 3/8 X 5.25 PLTD
11 86091710 140473 1 BRACKET, SQUEEGEE LIFT
12 86005630 57022 1 NUT, 3/8-16 HEX NYLOCK THIN SS
13 86009860 82541 1 WELDMENT, SQUEEGEE MOUNT
14 86088270 730121 1 STUD, 3/8-24 X 4.0 SS
15 86010050 82696 1 KNOB, 3/8-24 INSERT
16 86271980 57303 1 NUT, 3/8-24 WING, SS
