ACCESSORY PUMP-OPTION
86037580 GLIDE 01/03/07
5-68
REF
PART NO. PRV
NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86282170 39611 1 HOSE, 1/2 NYLOBRAID X 26
2 86233150 20042 6 CLAMP, 3/8 HOSE (D-SLOT)
3 86197550 40014 1 HOSEBARB, 1/4MPT X 3/8 DL
4 86081820 62838 1 PLATE, ACCESSORY BULKHEAD
5 86005580 56012 1 NIPPLE, 1/4 FPT OD
6 86240410 40078 1 HOSEBARB, 1/2 TEE
7 86273810 70018 2 SCR, 1/4-20 X 1 HHCS SS
8 86197940 40027 1 HOSEBARB, 3/8 MPT X 1/2 90 D DL
9 86006100 65176 1 PUMP ASM, 36V ACCESSORY
10 86001550 40043 1 HOSEBARB, 3/8 MPT X 3/8 90D
11 86281520 39413 1 HOSE, 3/8 NYLOBRAID X 17”
12 86226900 14236 2 U-BOLT, 1/4-20 X 1.5
13 86233370 80651 1 CLAMP, HOSE WORM DRIVE 2.7-3.7
14 86069980 140556 1 BRKT, PUMP MOUNT
15 86005810 57245 6 NUT, 1/4-20 HEX NYLOCK SS
16 86281000 39241 1 HOSE, 1/2 WIRE BOUND X 10”
