SCRUB DECK SIDE SQUEEGEE-28 IN DISK
86037580 GLIDE 01/03/07
5-18
5-18
REF PART
NO.
PRV
NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86094220
730106 1 SKIRT,
RIGHT
2
86082160
62923
1
PLATE, RIGHT DECK
3
86226830
73268
4
SPRING, EXT .68D X 3.00L X .098W
4
86007020
70673
6
SCR, 5/16-18 X 1.25 HHCS SS
5
86010670
87029
10
WASHER, 5/16 FLAT SS
6 86094230
730107 1 SKIRT,
LEFT
7
86005810
57245
6
NUT, 1/4-20 HEX NYLOCK SS
8
86007420
730100
2
SQUEEGEE, SIDE BLADE LINATEX
9
86276960
70773
6
SCR, 1/4-20 X1.0 CARRIAGE SS
10
86087920
730102
2
STRAP, SIDE SQUEEGEE
11
86276900
70753
2
SCR, 5/16-18 X 1.25 PFHMS SS NP
12
86279380
87146
16
WASHER, 1/2” ID X 1” D X .08” NYL
13
86082170
62924
1
PLATE, LEFT DECK
14
86272580
80638
4
PIN, CLEVIS 3/8” X 1.25” PLTD
15
86228840
09124
8
BEARING, FLANGED .314 D X .502 OD
16
86270830
57023
8
NUT, 5/16-18 HEX NYLOCK SS
17
86065960
05162
4
ARM, SKIRT LINKAGE
18
86259410
87206
8
WASHER, THRUST .51 ID X 1 OD X .063
19
86277090
70786
2
SCR, 5/16-18 X 3 HHMS FL THD SS
20
86005650
57031
2
NUT, 5/16-18 HEX
21
86272380
66217
4
PIN, CLEVIS 3/8 X 3/4
22
86242120
48090
2
KNOB, 1.0 OD X 5/16-18
23
86226810
73245
2
SPRING, COMP .72D X 2.0L X .067W
