Windsor Saber Glide 86037580 - Manual (Page 15)

SCRUB BRUSH/PAD DRIVER
86037580 GLIDE 01/03/07
5-14
5-14
28 IN. DISK:
REF PART NO.
PRV
NO.
QTY DESCRIPTION
SERIAL
NO.
NOTES:
1 86000250 02412 2 PAD DRIVER, 14” SD
2A 86000260 02413 2 BRUSH, 14” POLYPROPYLENE SD
2B 86000270 02414 2 BRUSH, 14” NYLON SD
2C 86000280 02416 2 BRUSH, 14” MILD GRIT SD
2D 86283850 02417 2 BRUSH, 14” SUPER AGG SD
3 86005070 51284 1
LOCK, PAD CENTER SNAP, TWO
STEP
4 86276590 70695 3 SCR, #12 X 1 PPHSMS SS
5 86210940 70694 1 SCR, 8-32 X 3/4 PTHMS
6 86276600 70696 3 SCR, #10 X 3/4 PTHSMS SS
7 86007910 73817 1 SPRING, EXT .31 D X 2.0 L X .03 W SS
8 86007280 730011 1 SOCKET, DRIVE BRUSH
9 86005940 62852 1 PLATE, BRUSH RELEASE
32 IN. DISK:
REF
PART
NO.
PRV
NO.
QTY DESCRIPTION
SERIAL
NO.
NOTES:
1 86000290 02418 2 PAD DRIVER, 16” SD
2A 86000300 02419 2 BRUSH, 16” POLYPROPYLENE SD
2B 86000310 02420 2 BRUSH, 16” NYLON SD
2C 86000330 02422 2 BRUSH, 16” MILD GRIT SD
2D 86000340 02423 2 BRUSH, 16” SUPER AGG SD
3 86005070 51284 1
LOCK, PAD CENTER SNAP, TWO
STEP
4 86276590 70695 3 SCR, #12 X 1 PPHSMS SS
5 86276580 70694 1 SCR, 8-32 X 3/4 PTHMS
6 86276600 70696 3 SCR, #10 X 3/4 PTHSMS SS
7 86007910 73817 1
SPRING, EXT .31 D X 2.0 L X .03 W
SS
8 86007280 730011 1 SOCKET, DRIVE BRUSH
9 86005940 62852 1 PLATE, BRUSH RELEASE
36 IN. DISK:
REF PART NO.
PART
NO.
QTY DESCRIPTION
SERIAL
NO.
NOTES:
1 86000170 02400 3 PAD DRIVER, 12” SD
2A 86000180 02401 3 BRUSH, 12” POLYPROPYLENE SD
2B 86168070 02402 3 BRUSH, 12” NYLON SD
2C 86000200 02404 3 BRUSH, 12” MILD GRIT SD
2D 86283820 02405 3 BRUSH, 12” SUPER AGG SD
3 86005070 51284 1
LOCK, PAD CENTER SNAP, TWO
STEP
4 86276590 70695 3 SCR, #12 X 1 PPHSMS SS
5 86276580 70694 1 SCR, 8-32 X 3/4 PTHMS
6 86276600 70696 3 SCR, #10 X 3/4 PTHSMS SS
7 86007910 73817 1 SPRING, EXT .31 D X 2.0 L X .03 W SS
8 86007280 730011 1 SOCKET, DRIVE BRUSH
9 86005940 62852 1 PLATE, BRUSH RELEASE
