SOLUTION DELIVERY
86037580 GLIDE 01/03/07
5-36
REF PART NO.
PRV
NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86273780 70015 1 SCR, 1/4-20 X 3/4 HHCS SS NP
2 86198050 81923 1 TEE, 3/4 FPT
3 86076820 40053 1 HOSEBARB, SOLUTION HOSE MTG
4 86005810 57245 1 NUT, 1/4-20 HEX NYLOCK SS
5 86282150 39596 1 HOSE, 1” X 28 VINYL
6 86236180 34387 1 FITTING, 3/4” COUPLING
7 86233300 20101 1 CLAMP, 1.25” WORM GEAR SS
8 86240150 39595 1 HOSE, 1 X 12” DRAIN
9 86233110 20018 1 CLAMP, 1.0” WORM GEAR
10 86240330 40051 1 HOSEBARB, 3/4 MPT X 1”H PVC DL
11 86233150 20042 1 CLAMP, 3/8 HOSE (D-SLOT)
12 86247760 80960 1 NIPPLE, 3/4 CLOSE
13 86256040 730151 1 STRAINER, 1/2 FPT 40 MESH
13A 86007250 730000 REF STRAINER, DEEP 40 MESH SERVICE ONLY
13B 86005870 59021 REF O-RING, FILTER SEAL SERVICE ONLY
14 86197910 40022 1 HOSEBARB, 1/2 MPT X 1/2 POLY
15 86236860 82362 1
FITTING, 3/4 MPT X 1/2 MPT
REDUCER
