Page 21
SCRUB DECK LIFT-28 IN &32 IN
86037580 GLIDE 11/05/08
5-20
REF PART
NO.
PRV
NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86272600
80657
1
PIN, COTTER HAIR .148” DIA X 3/4
*(2)
2
86014500
-
1
ACTUATOR, 36VDC 2.0 STRK SG28
*(3)
WAS
86000820
3
86008670
80606
4
COTTER, 3/8” RING
4
86092250
29254
1
DECK LIFT ASM
5
86008720
80637
3
PIN, CLEVIS 3/8” X 2.375 PLTD
6
86090270
87204
2
WASHER, RECTANGULAR HOLE
7 86077470
51362 2 LINK,
DECK
LIFT
8
86254880
730005
1
SPRING, COMP 1.687OD X 4.5L X .234W
9 86001320
140353 2 BALL
JOINT ASSY, 3/8-24 LH
10
86005830
57263
2
NUT, 3/8-24 UNF LH
11
86006440
67415
2
ROD, SCRUB LIFT
12
86005800
57217
2
NUT, 3/8-24 HEX JAM
13 86008810 80697 2 BALL
JOINT ASSY, 3/8-24 RH
14
86276920
70755
6
SCR, 3/8-16 X 1 HHCS SS NP
15
86008460
80102
6
SPACER, .500OD X .391ID X .400
16
86271530
57216
4
NUT, 3/8-24 HEX NYLOCK
17 86009050 81324 6 BEARING,
1/2ID X 11/32L NYLON
18
86005630
57022
6
NUT, 3/8-16 HEX NYLOCK THIN SS
19
86077330
31373
2
LINKAGE, .25 X 1.25 X 9.25
20 86066790
140503 1 BAR,
PANHARD
21
86248970
81406
2
PIN, CLEVIS 3/8 X 2
22
86276780
70728
1
SCR, 5-16-18 X 3/4 HHCS SS
23 86008550 80583 1 HORN,
36VDC
24
86270830
57023
1
NUT, 5/16-1/8 HEX NYLOCK SS
25
86005740
57112
2
NUT, 5/16-18 SERRATED FLG
26 86008740 80654 2 BUMPER,
ADJUSTMENT
*SEE SERIAL NUMBER PAGE.
