STEERING-UPPER
86037580 GLIDE 01/03/07 5-44
REF PART NO.
PRV
NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86234810 27945 1 COVER, STEERING WHEEL
2 86271610 57228 1 NUT, 5/8-18 HEX NYLOCK THIN
3 86259610 730117 1 WHEEL, STEERING 40 SPLINE HUB
4 86253230 730085 1 SHAFT, UPPER STEERING
5 86228790 09111 2 BEARING, FLANGE .88OD X .75ID X .75
6A 86093970 730118 1 COLUMN, UPPER STEERING 28 IN. & 32 IN.
6B 86092200 730160 1 COLUMN, 36 UPPER STEERING 36 IN.
7 86276890 70752 4 SCR, 5/16-8 X 3/4 PTHMS SS
8 86005810 57245 3 NUT, 1/4-20 HEX NYLOCK SS
9 86228580 09025 2 BEARING, 1/2 ID CYLINDER
10 86231260 140486 2 BUSHING, .50D X .26 X .3L SS
11 86075360 23697 1 COVER, STEERING COLUMN
12 86273820 70019 1 SCR, 1/4-20 X 1.25 HHCS
13 86255560 82855 1 SPRING, .31 X .04 X .3.0
14 86252060 67475 1 ROD, STEERING LOCK
15 86005620 57021 1 NUT, 1/4-20 X .962 WELL
16 86006410 67381 2 RING, 1/4 CLIP
17 86273810 70018 1 SCR, 1/4-20 X 1 HHCS SS
18 86005610 57016 2 NUT, 7/8 DIA PUSHLOCK
