SQUEEGEE-32 IN
86037580 GLIDE 01/03/07
5-40
REF PART
NO.
PRV
NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86009200
81535
3
KNOB, 3/8-16 4 PRONG ALUM
2
86005810
57245
2
NUT, 1/4-20 HEX NYLOCK SS
3
86276950
70772
2
SCR, 1/4-20 X 3/4 CARRIAGE SS
4
86164280
82922
4
KNOB, 1” BALL 5/16-18 INSERT
5
86065450
82532
1
PLATE, SLIDE SQUEEGEE LONG
6
86010770
87143
4
WASHER, 7/16ID X 1D X .08 FLT SS
7
86276980
70775
2
SCR, 5/16-18 X 2 HHCS SS
8
86277040
70781
1
SCR, 5/16-18 X 1/2 HHCS SS NP
9
86276440
70648
2
SCR, 8-32 X 7/8 PFHMS SS
10 86009910 82576 1 VIAL,
LEVEL
11
86010670
87029
4
WASHER, 5/16 FLAT SS
12
86270830
57023
2
NUT, 5/16-18 HEX NYLOCK SS
13
86008000
73887
2
SPRING, 120 DEGREE TORSION
14
86009170
81488
1
LATCH, SQUEEGEE STRAP
15
86009180
81489
1
STRIKER, SQUEEGEE STRAP REAR
16
86009820
82525
1
REAR SQUEEGEE BAND
17
86009890
82553
1
REAR SQG BAND SHORT
18
86006400
67380
4
RIVET, 5/32 OF X 1/8 GRIP
19
86276400
70642
1
SCR, 3/8-16 X 3 HHCS
20 86248230 82644 1 OVERLAY,
SQUEEGEE
21
86005630
57022
5
NUT, 3/8-16 HEX NYLOCK THIN SS
22
86008670
80606
2
COTTER 3/8” RING
23
86277140
70796
1
SCR, 1/4-20 X 2.0 THUMB SS TYPE P
24
86091450
140596
1
BAND, 32” FRONT SQUEEGEE
25
86276450
70649
1
SCR, 3/8-16 X 3.25 HHCS SS
26
86276430
70647
2
SCR, 3/8-16 X 1.75 HHCS SS
27
86009830
82528
1
SQUEEGEE, FRONT BLADE LINATEX
28
86009800
82518
1
PLATE, SQUEEGEE BLADE RETAINER
29A
86009840
82529
1
SQUEEGEE, REAR BLADE LINATEX
29B
86009960
82638
REF
SQUEEGEE REAR BLADE BLUE TILE
OPTION
29C
86009980
82641
REF
SQUEEGEE, REAR BLADE BUTTONS
OPTION
29D 86255700 730061 REF SQUEEGEE
BLADE
REAR URETHANE 37”
OPTION
30
86008720
80637
2
PIN, CLEVIS 3/8” X 2.375” PLTD
31 86263820 82799 1 PLATE,
POINTER
32
86274070
70086
1
SCR, 10-24 X 1/2 PPHMS SS
33
86270830
57023
2
NUT, 5/16-18 HEX NYLOCK SS
34 86001350 140390 4 BUSHING,
SPANNER .435 X 1.10
35
86011020
89202
4
WHEEL, 3” DIA CUSHION RUBBER
36
86276790
70732
2
SCR, 5/16-18 X 1.75 HHCS SS
37
86069030
140275
2
BRKT, SQUEEGEE WHEEL SUPPORT
38
86009790
82514
1
SQUEEGEE, 37 INCH
NOTE: COMPLETE SQUEEGEE ASSEMBLY IS AVAILABLE, PN 800615.
