FORWARD/REVERSE PEDAL
86037580 GLIDE 01/03/07 5-12
REF PART NO.
PRV
NO.
QTY DESCRIPTION
SERIAL
NO.
NOTES:
1 86005810 57245 3 NUT, 1/4-20 HEX NYLOCK SS
2 86007380 730088 1 SPACER, .50D X .26ID X 1.5L
3 86078310 66382 1 PEDAL, SMALL RIDER
4 86273850 70022 1 SCR, 1/4-20 X 2 HHCS
5 86276940 70758 1 SCR, 1/4-20 X 3.5 HHCS SS NP
6 86248340 66346 1 PAD, FWD/REV PEDAL
7 86006330 66343 1 POTENTIMETER, TROTTLE
8 86276930 70757 2 SCR, 8X1/2 PPH TYPE B SMS SP
9 86093140 51379 1 LINK, SMALL RIDER THROTTLE
10 86278060 70759 2 SET SCR, M4 X 4MM NP
11 86089660 78532 1 TUBE, 3/8 OD X 2.96 L
12 86091500 140577 1 BASE, SMALL RIDER PEDAL
13 86228750 09082 2 BEARING, 3/8” FLANGED NYLON
14 86273780 70015 1 SCR, 1/4-20 X 3/4 HHCS SS NP
15 86010300 830117 1 BRKT, SPRING ALIGNMENT
16 86010290 830116 3 SPRING, FLAT
17 86010680 87030 2 WASHER, 3/8 ID X 3/4 OD NYLON
